Technical specifications for 330102-00-40-10-11-05
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330102-00-40-10-11-05
-
Estimated shipping dimensions:1.5x1.3x119cm
-
Weight:0.15 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Unthreaded Length Option:0.0 in
-
Total Length Option:1.0 meter (3.3 feet)
-
Connector and Cable-Type Option:Miniature coaxial ClickLoc connector
-
Agency Approval Option:CSA, ATEX, IECEx Approvals
-
Overall Case Length Option:4.0 in
-
Target Material:AISI 4140 steel
-
Supply Voltage:-24 Vdc
Information
Overview
Manuals
Common Applications
Product Precautions
The 330102-00-40-10-11-05 proximity probe belongs to the 3300 XL 8mm sensor series, which is used for vibration and displacement monitoring of rotating machinery. In terms of hardware structure, the probe utilizes a patented TipLoc molding method, establishing a high-strength physical bond between the polyphenylene sulfide (PPS) plastic encapsulation at the tip and the metal body to withstand pressure and corrosion in industrial environments.
- One 3300 XL 8 mm probe
- One 3300 XL extension cable
- One 3300 XL Proximitor Sensor
The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable with other non XL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330102-00-40-10-11-05 Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power Generation
Monitors the radial vibration of the steam turbine main shaft.
Hydraulic Power Generation
Measures the axial displacement of large hydro-generator units.
Nuclear Power Generation
Monitors the mechanical condition of the reactor main feedwater pump.
Petroleum Refining
Monitors bearing conditions of centrifugal compressors in hydrocracking units.
Natural Gas Transmission
Measures vibration of gas turbine-driven pump groups on long-distance pipelines.
Air Separation Industry
Monitors the mechanical vibration of air compressor shafts in large air separation units.
During use, strictly control the probe installation gap to ensure the initial voltage centers within the linear range. Match the probe with an extension cable and Proximitor sensor for a total system length of 5m or 9m, avoiding any manual cable trimming. Connect cables with proper handling to prevent connector damage, and ensure the metal armor is reliably grounded to eliminate interference.
Alternative Names
330102 00 40 10 11 05
330102-00-40-10-11-00
330102-00-40-10-11-CN
330102-00-40-10-11-BR
330102-00-40-10-11-RU
330102-00-40-10-11-O5
330102-00-40-1O-11-05
330102-00-4O-10-11-05
330102-0O-40-10-11-05
330102-O0-40-10-11-05
3301O2-00-40-10-11-05
33O102-00-40-10-11-05
330102-00-40-10-1I-05
330102-00-40-10-I1-05
330102-00-40-I0-11-05
33010Z-00-40-10-11-05
33O1O2-OO-4O-1O-11-O5
330I02-00-40-I0-II-05
33OIOZ-OO-4O-IO-II-O5
Technical notes
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
FAQ View All FAQ
-
Do you offer global delivery services?Yes. We ship globally, and we are able to quickly deliver parts globally to any corner of the world. Unless otherwise specified, we will ship your order via (DHL). We can also ship through FedEx, UPS, and TNT. We can also use your account.
-
How many parts do you have in stock?We have an extensive stock base consisting of ten thousands of new and discontinued automation parts including those from leading manufacturers such as:Control Systems (DCS, PLC, CNC) ,Panel Controllers,HMI and Display Panels,Drives,Encoders and Resolvers,Power Supplies. If you are unable to find what you are looking for then don’t panic.
-
What components make up the eddy current proximity transducer system to which 330102-00-40-10-11-05 belongs?The system consists of a 3300 XL 8 mm probe, an extension cable, and a Proximitor Sensor.
-
What type of product is 330102-00-40-10-11-05?It is a 3300 XL 8 mm proximity probe, serving as the core measurement front-end of the eddy current proximity transducer system.
-
What is the primary operating principle of 330102-00-40-10-11-05?The system outputs voltage proportional to the distance between the probe tip and the conductive surface.
