      330101-00-08-10-02-00

      3300 XL 8 mm Proximity Probe, 3/8-24 UNF, Unarmored
      In Stock
      Ships by Sunday, November 8
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      The Bently Nevada 330101-00-08-10-02-00 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF mounting and without armor construction. It is used with a matched 3300 XL transducer system to provide a noncontacting signal for rotating-machine position and vibration measurements.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330101-00-08-10-02-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330101-00-08-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330101-00-08-10-02-00
      • Estimated shipping dimensions:
        110x1.5x1.2cm
      • Weight:
        0.04 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        3300 XL 8 mm
      • Base probe model:
        330101
      • Mounting thread:
        3/8-24 UNF
      • Cable protection:
        Without armor
      • Unthreaded length:
        0.0 in
      • Overall case length:
        0.8 in
      • Total probe length:
        1.0 m
      • Connector:
        Miniature coaxial ClickLoc
      • Cable type:
        Standard cable
      • Agency approval option:
        Not required
      • Probe tip diameter:
        8.0 mm
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330101-00-08-10-02-00 is an unarmored standard-mount proximity probe for the 3300 XL 8 mm Proximity Transducer System. In the matched system, it supplies a non-contact eddy-current signal for machinery monitoring.
      • •Non-contact sensing within a matched 3300 XL measurement system
      • •Supports shaft-vibration and static-position monitoring
      • •Works with the documented extension-cable and Proximitor Sensor arrangement
      • •Supports Keyphasor and speed-related sensing where manufacturer requirements are met

      Install the probe in the documented machine location, protect the integral cable and ClickLoc connector, and confirm the conductive target, operating gap and monitoring-channel response during commissioning.

      Important Notice: Verify the complete 330101-00-08-10-02-00 nameplate, companion components, machine drawing and current Bently Nevada instructions before use.

      Apter Power 330101-00-08-10-02-00 Manuals and Guides

      Apter Power 330101-00-08-10-02-00 Product Technical Reference PDFBently Nevada 3300 XL 8 mm Proximity Transducer System Datasheet 141194 Rev. AM

      The first document presents model-specific technical identity and engineering data. The second is the unmodified manufacturer datasheet containing the 3300 XL 8 mm system description, ordering codes, installation limits and dimensional figures.

      330101-00-08-10-02-00 radial shaft vibration

      Provides the probe interface for non-contact observation of dynamic shaft motion on fluid-film-bearing rotating machinery.

      330101-00-08-10-02-00 axial or static position

      Tracks shaft displacement when target geometry, operating gap and the matched transducer loop meet the documented conditions.

      330101-00-08-10-02-00 Keyphasor reference

      Supplies a phase-reference sensing point for compatible machinery-monitoring channels and documented target arrangements.

      330101-00-08-10-02-00 speed-related sensing

      Supports speed measurement when applied with the manufacturer's proximity-probe guidance and an approved monitoring channel.

      Read Bently Nevada publication 141194 Rev. AM before installing 330101-00-08-10-02-00, and verify the complete ordering code and installed system configuration.

      1Confirm the complete 330101-00-08-10-02-00 label and approval option on the physical probe.
      2Verify thread engagement, case clearance, probe-holder geometry and target position against the machine drawing.
      3Protect the integral lead and ClickLoc connector from crushing, contamination, sharp bends and tensile loading.
      4Match the probe, extension-cable arrangement and Proximitor Sensor to the documented system length.
      5Verify conductive target geometry and establish the operating gap with the approved commissioning procedure.
      6Document final mounting, routing, connection and signal checks before returning the monitored machine to service.

      Technical notes

      Configure 330101-00-08-10-02-00 only as a component of a matched 3300 XL probe, companion cable arrangement and Proximitor Sensor system. Verify the ordered mechanical configuration, target, gap and installed routing before commissioning.

      FAQ View All FAQ

      • What is Bently Nevada 330101-00-08-10-02-00 used for?
        It is used as the proximity probe element of a matched 3300 XL system for noncontacting rotating-machine vibration and position measurements.
      • Which mounting configuration applies to Bently Nevada 330101-00-08-10-02-00?
        Confirm the complete model label and documented 3/8-24 UNF mounting arrangement before fitment.
      • How should Bently Nevada 330101-00-08-10-02-00 be paired?
        Pair it only with the installed compatible 3300 XL Proximitor Sensor and companion cable arrangement.
      • Can Bently Nevada 330101-00-08-10-02-00 be installed as a stand-alone device?
        No. Its measurement function depends on the complete matched 3300 XL transducer system.
      • What should be checked before wiring Bently Nevada 330101-00-08-10-02-00?
        Inspect the ClickLoc connector, protected cable route and approved field wiring for the installed host system.
      • How should Bently Nevada 330101-00-08-10-02-00 be commissioned?
        Verify the physical label, target material, approved gap procedure and expected machine-monitoring signal before service.
      • What does the approval option on Bently Nevada 330101-00-08-10-02-00 require?
        The ordered approval option is Not required. Confirm the installed equipment requirements before use.
      • When can Bently Nevada 330101-00-08-10-02-00 be replaced?
        Replace it only after confirming the exact ordering code, mechanical configuration and matched-system requirements in project records.
