Get a quick price for 3300/45-02-01-02-00
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 3300/45-02-01-02-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:3300/45-02-01-02-00
-
Estimated shipping dimensions:2.5×12.8×4cm
-
Weight:0.26 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Monitor type:Dual differential expansion
-
Measurement channels:2
-
Transducer inputs:Paired proximity transducers
-
Host system:Bently Nevada 3300
-
Requested alias:3300/45
Information
Overview
Manuals
Common Applications
Product Precautions
3300/45-02-01-02-00 calculates two differential-expansion measurements from paired proximity-transducer signals in a 3300 rack.
- Calculates differential expansion from paired proximity inputs
- Provides two independent machine-expansion channels
- Supports alert and danger supervision in the 3300 rack
- Preserves the configured order execution and channel pairing
The monitor operates with four installed proximity-transducer signals arranged as two differential pairs. Commissioning includes rack position, input pairing, polarity, zero, alarm setpoints, recorder outputs and controlled response checks.
Important Notice: Confirm 3300/45-02-01-02-00, 3300 rack, hardware revision, four proximity inputs, two differential pairs, probe polarity, scale factors, zero positions, alarm setpoints, recorder outputs, grounding and controlled channel-test results before commissioning.
Apter Power 3300/45-02-01-02-00 Manuals and Guides
- Apter Power 3300/45 Dual Differential Expansion Technical Reference PDF
- Apter Power 3300/45 Channel Pairing and Alarm Verification Workbook PDF
The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.
Steam-turbine differential expansion
Supervises rotor-to-casing growth using paired axial probe locations.
Compressor case-expansion monitoring
Tracks relative axial movement across documented machine reference points.
Large rotating-train startup
Provides differential expansion indication during controlled thermal growth.
3300 monitor replacement
Restores the configured two-channel monitor while retaining transducer pairing.
Read the applicable Bently Nevada installation instructions before work. Verify 3300/45-02-01-02-00, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
1
Confirm 3300/45-02-01-02-00 and the recorded 3300 rack position.
2
Place the machine and associated trip logic in the approved maintenance state.
3
Record all four transducer inputs and their two differential channel pairs.
4
Capture zero positions, alert/danger settings and recorder scaling before removal.
5
Inspect rack connector, grounding and input cable shields.
6
Restore the exact channel pairing and configured transducer scale factors.
7
Verify monitor OK status, zero and each recorder or display output.
8
Apply controlled paired inputs and prove both differential alarms before release.
Alternative Names
3300/45
Technical notes
Install 3300/45-02-01-02-00 in the recorded 3300 monitor position and preserve both paired-transducer channel assignments, alarm settings and recorder connections. Verify probe polarities, differential calculations, zero positions and alarm actions with controlled mechanical or simulated inputs.
FAQ View All FAQ
-
Which complete article marking distinguishes 3300/45-02-01-02-00 from nearby variants?Confirm 3300/45-02-01-02-00, 3300 rack, hardware revision, four proximity inputs, two differential pairs, probe polarity, scale factors, zero positions, alarm setpoints, recorder outputs, grounding and controlled channel-test results before commissioning.
-
What system function is assigned specifically to 3300/45-02-01-02-00?Calculates differential expansion from paired proximity inputs. It combines paired proximity-transducer measurements to supervise differential expansion at two machine locations.
-
How should the host position and mating hardware for 3300/45-02-01-02-00 be verified?The monitor operates with four installed proximity-transducer signals arranged as two differential pairs. Commissioning includes rack position, input pairing, polarity, zero, alarm setpoints, recorder outputs and controlled response checks.
-
Which power, signal or field circuits must be controlled before servicing 3300/45-02-01-02-00?Place the machine and associated trip logic in the approved maintenance state. Record all four transducer inputs and their two differential channel pairs.
-
What wiring or connector checks are required for 3300/45-02-01-02-00?Restore the exact channel pairing and configured transducer scale factors.
-
How is the approved software or hardware setup for 3300/45-02-01-02-00 preserved?Verify monitor OK status, zero and each recorder or display output.
-
Which alarms or status indications should be reviewed after replacing 3300/45-02-01-02-00?Confirm 3300/45-02-01-02-00 and the recorded 3300 rack position. Inspect rack connector, grounding and input cable shields.
-
How is a controlled functional release completed for 3300/45-02-01-02-00?Apply controlled paired inputs and prove both differential alarms before release.
