      143493-00-080-080-70-00

      Proximity Probe
      In Stock
      Ships by Sunday, November 8
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      3300 XL NSv Proximity Probe
      80 mm Case Length
      8.0m Total System Length
      Integrated Connector Protector

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 143493-00-080-080-70-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 143493-00-080-080-70-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        143493-00-080-080-70-00
      • Estimated shipping dimensions:
        35x22x2cm
      • Weight:
        0.22 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Thread Type:
        3/8-24 UNF
      • Armor:
        Without armor
      • Unthreaded Length:
        8.0 in
      • Overall Case Length:
        8.0 in
      • Connector Option:
        ClickLoc with connector protector, standard cable
      • Linear Range:
        1.5 mm (60 mils)
      Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      The 143493-00-080-080-70-00 is a 3300 XL NSv Proximity Probe, primarily configured for machines with tight installation requirements, such as centrifugal air compressors, refrigeration compressors, and process gas compressors.
        • Non-contacting vibration and displacement measurements in restricted spaces
        • Phase reference (Keyphasor) signals
        • Tachometer and zero speed measurements
      This model features a 3/8-24 English unarmored threaded case with a physical thread length of 80 mm and a total sensing system length of 8.0 meters. The physical structure integrates gold-plated brass ClickLoc locking connectors, a moisture-proof connector protector, as well as high-strength TipLoc tip molding and CableLoc cable anchoring technologies to withstand up to 330 Newtons of cable pull strength, ensuring long-term operational reliability in harsh industrial conditions such as moisture and oil contamination.

      The system provides comprehensive certification compliance to secure operations in hazardous areas and enables seamless signal interfacing with the Bently Nevada 3500 monitoring system. The thermoplastic PPS material utilized for the probe tip and the included locknut with pre-drilled holes enhance overall wear and chemical corrosion resistance, while allowing the use of safety wire for strict secondary physical loosening prevention, thereby significantly extending the mean time between failures under severe, continuous industrial operations.

      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
       Bently Nevada 143493-00-080-080-70-00 Proximity Probe Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Air Separation Industry
      Monitors impeller shaft vibration of single or multi-stage integrally geared large centrifugal air compressors.

      Refrigeration & HVAC Industry
      Monitors axial displacement of hermetic refrigeration screw or centrifugal compressors in large industrial chillers.

      Petroleum Refining & Petrochemicals
      Monitors radial vibration of high-speed shafts on small-flow, high-speed centrifugal pumps in refineries.

      Coal Chemical Industry
      Used for rod position and rod drop monitoring on reciprocating high-pressure syngas compressors.

      Semiconductor & Electronics Manufacturing
      Monitors bearing clearances of high-speed nitrogen/argon circulation compressors with ultra-clean factory requirements.

      Pharmaceutical Chemical Industry
      Monitors relative casing displacement of high-speed miniature turbine-driven fans in sterile material transfer systems.
       When using the 143493-00-080-080-70-00 probe you must adhere to the minimum spacing limits of the Narrow Side View system to prevent electromagnetic cross-talk and erroneous readings on small shaft diameters. During installation you must precisely calibrate the initial gap voltage and avoid over-tightening or excessive pulling on the cable.

      Furthermore after mating the ClickLoc coaxial connectors you must seal the junction entirely with oil-proof self-fusing tape or a connector protector to prevent lubrication oil and moisture ingress.

      Alternative Names

      143493-OO-O8O-O8O-7O-OO I43493-00-080-080-70-00 143493-00-080-080-70-CN 143493-00-080-080-70-RU 143493 00 080 080 70 00 143493-00-080-080-70-BR 143493-00-080-080-70-05 143493-00-080-040-50-00

      Technical notes

      143493-00-080-080-70-00 utilizes gold-plated brass ClickLoc connectors across all components that lock into place to prevent loosening. The probe features patented TipLoc molding to establish a robust bond between the probe tip and body, along with a secure CableLoc structure to withstand severe environments.

      FAQ View All FAQ

      • How many parts do you have in stock?
        We have an extensive stock base consisting of ten thousands of new and discontinued automation parts including those from leading manufacturers such as:Control Systems (DCS, PLC, CNC) ,Panel Controllers,HMI and Display Panels,Drives,Encoders and Resolvers,Power Supplies.
      • Do you offer global delivery services?
        Yes. We ship globally, and we are able to quickly deliver parts globally to any corner of the world. Unless otherwise specified, we will ship your order via (DHL). We can also ship through FedEx, UPS, and TNT. We can also use your account.
      • What is the 143493-00-080-080-70-00?
        The 143493-00-080-080-70-00 is a 3300 XL NSv series narrow gap proximity probe manufactured by Bently Nevada.
      • What is the primary application of the 143493-00-080-080-70-00?
        The 143493-00-080-080-70-00 measures vibration and displacement in compact rotating machinery with small targets or restricted installation spaces.
      • How to use products like the 143493-00-080-080-70-00?
        Thread the probe into the bearing housing toward the shaft surface, tighten the locknut, and connect the connector to a Proximitor via an extension cable.
