      16710-06

      Armored Interconnect Cable
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 16710-06 is a six-foot armored, shielded three-conductor interconnect cable in the 16710 family for documented accelerometer installations. It has a three-socket sensor-side plug and terminal-lug receiving end; verify the installed mating connector, route and terminal assignments before replacement.

      Ask our team:

      Get a quick price for： 16710-06
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 16710-06

      Technical specifications for 16710-06

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        16710-06
      • Estimated shipping dimensions:
        31x28x2cm
      • Weight:
        0.16 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Article type:
        Armored accelerometer interconnect cable
      • Order length:
        6 ft (approximately 1.8 m)
      • Conductors:
        Three, shielded
      • Conductor gauge:
        22 AWG
      • Protection:
        Armored construction
      • Sensor-side connection:
        Three-socket plug
      • Receiving-end connection:
        Terminal lugs
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 16710-06 is a six-foot armored, shielded three-conductor cable for a compatible accelerometer connection.
      • Six-foot armored interconnect in the 16710 cable series
      • Shielded three-conductor 22 AWG cable core
      • Three-socket plug for the sensor-side connection
      • Separate terminal lugs at the receiving end

      The -06 suffix selects the six-foot cable execution. Keep the documented sensor plug, receiving-end lugs and shield route matched to the installed channel.

      Important Notice: Verify the complete 16710-06 marking and approved cable path before disconnecting or replacing either end.

      Bently Nevada 16710-06 Manuals & Downloads
      Bently Nevada 16710-06 Technical Reference (PDF)Bently Nevada 16710-06 Installation & Commissioning Guide (PDF)

      The technical reference records cable construction and interfaces; the separate field guide covers matching, termination and functional acceptance for the six-foot run.

      Accelerometer connectionLink a documented compatible 330400 or 330425 accelerometer to its assigned receiving channel.
      Protected machine routeRetain the approved armored cable path through mechanically exposed plant areas.
      Six-foot cable renewalReplace a documented -06 run while preserving plug, lug and shield assignments.
      Receiving-circuit terminationLand individual lugs at the documented monitoring terminals and verify channel response.
      Read the applicable Bently Nevada accelerometer and receiving-system instructions before work. Verify 16710-06, both cable interfaces and the approved maintenance state.
      1
      Match the complete 16710-06 marking and six-foot route to the maintenance record.
      2
      Place the connected machine and receiving channel in their approved maintenance state.
      3
      Record the as-found three-socket plug, armor path, terminal lugs and shield.
      4
      Inspect the mating sensor interface and reject bent or contaminated contacts.
      5
      Route the armored cable without crushing the shielded three-conductor core.
      6
      Restore each lug and shield termination from the approved circuit drawing.
      7
      Check cable continuity and connection condition before controlled energization.
      8
      Confirm receiving-channel diagnostics and measured response before release.

      Technical notes

      Technical notes

      Bently Nevada 16710-06 is a 6 ft armored interconnect cable in the 16710-AA family. Manufacturer literature identifies a shielded three-conductor 22 AWG core, three-socket sensor-side plug and terminal lugs at the receiving end. Cable-only data must not be confused with connected accelerometer electrical ratings. Basis: Baker Hughes / Bently Nevada 177230 Seismic Transmitter Datasheet 177232 Rev. T, ordering page 7; 330400/330425 Accelerometers Datasheet 141638 Rev. AA, cable ordering section.

      FAQS

      • What length does the 06 suffix specify on 16710-06?
        The 16710-AA length field is in feet, so 06 denotes a 6 ft armored cable. Confirm the installed run before ordering.
      • Where does the three-socket plug on 16710-06 connect?
        It is the sensor-side connection. Check the mating accelerometer receptacle and approved wiring drawing.
      • How is the opposite end of 16710-06 terminated?
        The receiving end uses terminal lugs. Retain each conductor and shield termination as documented.
      • Is 16710-06 the same construction as an unarmored 16925 cable?
        No. 16710 is armored while 16925 is unarmored; matching a connector alone does not establish interchangeability.
      • Can accelerometer sensitivity be assigned to the 16710-06 cable?
        No. Sensitivity belongs to the connected sensor and complete measurement channel, not the cable by itself.
      • What should be checked after fitting 16710-06?
        Inspect cable routing and terminations, then verify continuity, monitor diagnostics and controlled channel response before release.
