Technical specifications for 6DP1230-8CC
-
Manufacturer:Siemens
-
Product Category:DCS Systems
-
Spare Part Number:6DP1230-8CC
-
Estimated shipping dimensions:2x26.3x26.2cm
-
Weight:0.33 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Module designation:FUM 230
-
Module type:Analog signal-conditioning module
-
Input channels:16
-
Input signal:0/4 to 20 mA
-
Supported field circuits:2-wire or 4-wire
-
Transducer supply:24 V DC
-
Limit values:4 per channel
-
Signal correction:Supported
-
Monitoring:Supply, range and wire-break conditions
-
Redundant operation:Suitable
Information
Overview
Manuals
Common Applications
Product Precautions
In a FUM 230 signal-conditioning position, Siemens 6DP1230-8CC collects sixteen transmitter current loops and supervises each assigned measurement path.
- 6DP1230-8CC
- FUM 230
- Analog signal-conditioning module
- 16
Retain the exact host position, connections and configuration record. Complete controlled diagnostics and a functional test before service release.
Important Notice: Confirm 6DP1230-8CC, every companion marking and the recorded acceptance result before replacement.
Siemens 6DP1230-8CC Manuals & Downloads
Siemens 6DP1230-8CC Technical Reference (PDF)Siemens 6DP1230-8CC Installation & Commissioning Guide (PDF)
The technical reference consolidates product identity and interface data; the installation guide provides separate readiness, configuration, verification and handover checks.
Sixteen-loop transmitter acquisition
Collects sixteen 0/4 to 20 mA field signals in one FUM 230 module position.
Two-wire and four-wire loop service
Supports the two documented transmitter circuit arrangements without changing the exact module identity.
Per-channel limit processing
Uses four limit values per channel together with the configured signal-correction function.
Supervised or redundant measurement paths
Monitors supply, range and wire-break conditions and is suitable for a redundant execution.
Read the applicable product and site instructions before work. Verify 6DP1230-8CC, the installed host and every connected interface before isolation or replacement.
1
Confirm the complete 6DP1230-8CC marking and the FUM 230 designation before work.
2
Record all sixteen channel assignments and the existing 0/4 to 20 mA configuration.
3
Identify every connected loop as a 2-wire or 4-wire transmitter circuit.
4
Isolate the affected measurement paths and verify the 24 V DC transmitter-supply boundary.
5
Restore the four configured limit values for each channel that uses limit processing.
6
Restore the approved signal-correction settings without borrowing values from another channel.
7
Test transmitter-supply, range-overshoot, range-undershoot and wire-break monitoring.
8
Where redundant operation is used, verify both acquisition paths before service release.
Technical notes
Set every Siemens 6DP1230-8CC channel for its installed current range and 2-wire or 4-wire circuit before energizing transmitter supply. Verify limit handling, signal correction, range monitoring and wire-break indication; where redundancy is used, confirm both acquisition paths.
FAQ View All FAQ
-
How many analog input channels does Siemens 6DP1230-8CC provide?The FUM 230 module provides sixteen analog transmitter input channels.
-
Which current ranges can Siemens 6DP1230-8CC accept?Its documented input range is 0 to 20 mA or 4 to 20 mA.
-
Can Siemens 6DP1230-8CC connect to both 2-wire and 4-wire transmitters?Yes. The data sheet lists both 2-wire and 4-wire transmitter circuits.
-
What transmitter supply does Siemens 6DP1230-8CC provide?The module provides a 24 V DC transducer supply for the connected transmitter circuits.
-
How many limit values can Siemens 6DP1230-8CC process per channel?Four limit values can be configured for each channel.
-
Does Siemens 6DP1230-8CC support signal correction?Yes. Signal correction is a documented FUM 230 function.
-
Which input conditions can Siemens 6DP1230-8CC monitor?It monitors the transmitter supply, measurement-range overshoot and undershoot, and wire break.
-
Is Siemens 6DP1230-8CC suitable for redundant operation?Yes. The exact-model data sheet identifies the module as suitable for redundant use.
