      6ES7414-2XL07-0AB0

      CENTRAL PROCESSING UNIT
      In Stock

      Product Describe：

      6ES74142XL070AB0
      CENTRAL PROCESSING UNIT
      CPU 414-2
      WORK MEMORY 2 MB
      1ST INTERFACE MPI/DP
      12 MBIT/S
      2ND INTERFACE PROFIBUS DP

      Ask our team:

      Get a quick price for： 6ES7414-2XL07-0AB0
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information FAQ More Details

      Technical specifications for 6ES7414-2XL07-0AB0

      Technical specifications for 6ES7414-2XL07-0AB0

      • Manufacturer:
        Siemens
      • Product Category:
        PLC Systems
      • Spare Part Number:
        6ES7414-2XL07-0AB0
      • Estimated shipping dimensions:
        2.4x22.2x29cm
      • Weight:
        0.74 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Germany
      • PROFIBUS DP Interface:
        12 Mbit/s
      • Working Memory:
        768 KB
      • Power Supply Voltage:
        Typically +24V DC
      • Temperature Range:
        0°C to +60 °C
      • Working Memory (Data):
        128 KB
      • Power Loss:
        7.5 W
      • Number of points:
        Supports a maximum of 131072 inputs/outputs.
      • Analog Channel:
        Supports up to 8192 inputs/outputs.
      • Interface 1:
        Combining MPI and PROFIBUS DP (master/slave), with a maximum speed of 12 Mbit/s.
      • Interface 2:
        Independent PROFIBUS DP (master/slave) with a maximum speed of 12 Mbit/s.
      • Working memory:
        2 MB in total (1 MB each for code and data), non expandable.
      • Loading memory:
        It can be expanded up to 64 MB through a storage card (RAM or FEPROM).
      • Processing speed:
        Binary instruction execution takes only 18.75 ns, suitable for high-speed control
      Ask for Quote

      Information

      Information

      Overview Manuals Main functions
      The Siemens SIMATIC S7-400 CPU 414-2 (6ES7414-2XL07-0AB0) is a high-performance, mid-range central processing unit with 2 MB total work memory (1 MB for code, 1 MB for data).
        • SIMATIC S7-400
        • CPU 414-2 Central processing unit
        • 1st interface MPI/DP 12 Mbit/s
      The central processing unit module (CPU 414-2) is a core component designed for mid to high end performance requirements in the SIMATIC S7-400 series. It is equipped with up to 2 MB of built-in working memory, with 1 MB each for programs and data, ensuring efficient operation of complex control logic.
      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Siemens 6ES7414-2XL07-0AB0 CENTRAL PROCESSING UNIT Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      1. Powerful logical processing and computing capabilities 2. Dual Integrated Communication Interface (Multi Interface) 3. Distributed I/O management and control 4. Advanced Diagnosis and Data Protection

      FAQS

      • What is 6ES7414-2XL07-0AB0?
        6ES7414-2XL07-0AB0 is a Central Processing Unit
      • What is the memory breakdown?
        The 2 MB memory is split into 1 MB for the program code and 1 MB for data (load memory is not explicitly stated in snippets but is supported).
      • Can this CPU handle PROFIBUS DP?
        Yes, it has built-in DP interfaces for PROFIBUS communication.
      • What software is required for programming?
        The S7-400 CPU 414-2 is configured with STEP 7 V5.5 SP1 or higher or TIA Portal.
      • Is it suitable for large systems?
        Yes, it is part of the S7-400 line designed for high-performance applications.
