6GK7443-1EX30-0XE0

CP443-1 Communications Processor
In Stock
Siemens 6GK7443-1EX30-0XE0
Siemens 6GK7443-1EX30-0XE0
Siemens 6GK7443-1EX30-0XE0
Siemens 6GK7443-1EX30-0XE0
Siemens 6GK7443-1EX30-0XE0
Siemens 6GK7443-1EX30-0XE0
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

6GK74431EX300XE0
COMMUNICATIONS PROCESSOR
CP443-1
2X 10/100 MBIT/S (IE SWITCH)
RJ45 PORTS
ISO/TCP/UDP
PROFINET IO CONTROLLER
S7 COMMUNICATION
SEND/RECEIVE
S7 ROUTING
IP ACCESS CONTROL LIST
TIME SYNCHRONIZATION
Get a quick price for 6GK7443-1EX30-0XE0
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 0

    Why Choose Apter Power?

    1.Full one year warranty on all components
    2.Professional after selling team
    3.Same-day dispatch payment come
    4.All units are fully tested well with certificate
    5.Speak With an Expert Sales Representative
    6.More than 20 years experience in automation
    7.Stable employees more than 10+ years working experience
  • 1

    Common Applicationsations

    • Automotive & Assembly
    • Energy & Power Monitoring
    • Water & Infrastructure
    • Oil & Gas
    • Warehousing
    • Pharmaceutical
  • 2

    Delivery and payment

    Delivery
    Logistic partners UPS, FedEx and DHL
    International delivery available
    Same day dispatch from warehouse inventory
    Warranty
    All parts new original are covered by Apterpower 12 month warranty


Technical specifications for 6GK7443-1EX30-0XE0

  • Manufacturer:
    Siemens
  • Product Category:
    PLC Systems
  • Spare Part Number:
    6GK7443-1EX30-0XE0
  • Estimated shipping dimensions:
    4x11.7x12.5cm
  • Weight:
    0.2 kg
  • Tariff Code:
    8537101190
  • Counliy of origin:
    Germany
  • Number of Ports:
    1 Ethernet port
  • Baud Rate:
    10/100 Mbps full/half-duplex
  • Power Supply:
    24 VDC
  • Power Consumption:
    3W
  • Minimum Ambient Operating Temp.:
    0°C
  • Maximum Ambient Operating Temp.:
    60°C
  • Protection Rating:
    IP20
  • Certifications:
    CE, UL, and cULus

Information

Overview Manuals Common application scenarios
The 6GK7443-1EX30-0XE0 is a high-performance industrial Ethernet communication processor from Siemens SIMATIC S7-400 series, commonly known as CP 443-1. It is the core gateway that connects the S7-400 PLC with the upper computer (SCADA), HMI, or other controllers.
    • Communications processor CP 443-1
    • 2x 10/100 Mbit/s (IE switch)
    • Open communication (SEND/ RECEIVE)
In modern digital factories, 6GK7443-1EX30-0XE0 demonstrates extremely high flexibility and compatibility. It not only supports high-speed real-time communication (Real Time) in industrial Ethernet environments, but also helps enterprises achieve energy management by supporting the PROFIenergy protocol.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Siemens 6GK7443-1EX30-0XE0 Communications Processor Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Factory backbone network: used for large-scale data exchange between S7-400 and upper computer (SCADA/HMI) or other PLCs. Distributed I/O: Managing large-scale PROFINET remote stations. Redundant system: used in S7-400H high availability system.

FAQ View All FAQ

  • What programming software does this 6GK7443-1EX30-0XE0 module support?
    Supports STEP 7 V5.5 SP2 or higher versions. If using TIA Portal, it is recommended to use V11 or higher version.
  • How many PROFINET IO devices can the 6GK7443-1EX30-0XE0 carry?
    As a PROFINET IO controller, it can connect up to 128 IO devices.
  • What is the 6GK7443-1EX30-0XE0 maximum number of connection loops?
    This module supports up to 128 active communication connections (including S7 communication, TCP, UDP, etc.).
  • What is the 6GK7443-1EX30-0XE0 difference between two RJ45 ports?
    Two ports integrate industrial Ethernet switch functionality and support linear topology. They share the same IP address and are logically an interface.
  • What clock synchronization protocols are supported?
    Supports NTP protocol and SIMATIC program mode (as a time slave).
  • Does the 6GK7443-1EX30-0XE0 support Gigabit Ethernet?
    Not supported. Only supports 10/100 Mbit/s adaptation.
  • What does the BF light flashing red mean?
    Bus Fault. Usually it is because the configured IO device is disconnected, the network cable is damaged, or the PROFINET name does not match.
