Technical specifications for 6DD1607-0EA1
-
Manufacturer:Siemens
-
Product Category:General Automation
-
Spare Part Number:6DD1607-0EA1
-
Estimated shipping dimensions:29x4.8x21.1cm
-
Weight:0.88 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Module designation:EXM 448-1
-
Hardware type:Communication expansion module
-
Host platform:FM 458
-
PROFIBUS function:PROFIBUS DP communication
-
SIMOLINK function:Integrated SLB interface
-
Engineering environment:D7-SYS with STEP 7 / CFC
-
Replacement basis:Exact order number and configured networks
-
Acceptance:Bus configuration, diagnostics and data exchange
Information
Overview
Manuals
Common Applications
Product Precautions
Within an FM 458 control configuration, Siemens 6DD1607-0EA1 adds two communication paths while retaining the configured PROFIBUS and SIMOLINK relationships.
- Uses the EXM 448-1 communication expansion architecture.
- Provides a PROFIBUS DP communication function.
- Includes an integrated SLB interface for SIMOLINK.
- Works with D7-SYS engineering in STEP 7 and CFC.
Keep the FM 458 hardware position, PROFIBUS station data and SIMOLINK sequence together as one controlled configuration. Commission both communication paths before the controller is returned to operation.
Important Notice: An EXM 448-1 replacement is acceptable only after its complete 6DD1607-0EA1 marking and both configured networks have been verified.
Siemens 6DD1607-0EA1 Manuals & Downloads
Siemens 6DD1607-0EA1 Technical Reference (PDF)Siemens 6DD1607-0EA1 Installation & Commissioning Guide (PDF)
Use the reference for EXM 448-1 identity and interface boundaries; use the commissioning guide to restore FM 458, PROFIBUS DP and SIMOLINK relationships in a controlled sequence.
FM 458 communication expansion
Adds the documented EXM 448-1 communication functions to the assigned controller position.
PROFIBUS DP integration
Connects the configured PROFIBUS DP station without changing the recorded bus relationship.
SIMOLINK coordination
Maintains the integrated SLB path and the established SIMOLINK device sequence.
D7-SYS service replacement
Supports exact-module renewal followed by STEP 7 or CFC diagnostics and data-exchange checks.
Treat 6DD1607-0EA1 as part of one FM 458 communication configuration. Preserve both network records before disturbing the installed module.
1
Match the complete order number and EXM 448-1 designation.
2
Place the FM 458 application in its approved maintenance state.
3
Save the D7-SYS, STEP 7 or CFC configuration before removal.
4
Label the PROFIBUS DP and SIMOLINK connections separately.
5
Record the bus address, port use and companion-module arrangement.
6
Restore seating, shielding and the documented network sequence.
7
Review FM 458 and EXM 448-1 diagnostics after energization.
8
Prove PROFIBUS DP and SIMOLINK data exchange before release.
Technical notes
Match Siemens 6DD1607-0EA1 to the complete installed record, host position and companion hardware. Preserve connections and settings; then verify diagnostics and PROFIBUS DP and SIMOLINK communication expansion for an FM 458 system under controlled conditions.
FAQ View All FAQ
-
What does 6DD1607-0EA1 identify?6DD1607-0EA1 identifies the exm 448-1 communication expansion module used for PROFIBUS DP and SIMOLINK communication expansion for an FM 458 system.
-
Which installed system must 6DD1607-0EA1 match?Match 6DD1607-0EA1 to the recorded FM 458 / SIMADYN D host, position and companion hardware.
-
Which markings must be checked on 6DD1607-0EA1?Verify the complete 6DD1607-0EA1 text and every suffix, revision or assembly marking on the supplied item.
-
What should be recorded before removing 6DD1607-0EA1?Record the slot, connectors, cable labels, switches, parameters, adjacent hardware and diagnostic state.
-
Can 6DD1607-0EA1 be replaced by appearance alone?No. 6DD1607-0EA1 requires an exact identity and interface match against the installed-system record.
-
How should 6DD1607-0EA1 be isolated?Use the approved maintenance state, remove connected energy and prove the affected circuit safe.
-
What is checked after installing 6DD1607-0EA1?Check mechanical seating, wiring, settings, communication, diagnostics and every affected function.
-
What releases 6DD1607-0EA1 to service?A recorded acceptance test must confirm PROFIBUS DP and SIMOLINK communication expansion for an FM 458 system without unexpected alarms or process response.
