Technical specifications for 6GK5308-2FM10-2AA3
-
Manufacturer:Siemens
-
Product Category:General Automation
-
Spare Part Number:6GK5308-2FM10-2AA3
-
Estimated shipping dimensions:12×13×12.5cm
-
Weight:1.16 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product type:SCALANCE X308-2LD managed plus IE switch
-
10/100 RJ45 ports:7
-
10/100/1000 RJ45 ports:1
-
1000 Mbit/s optical ports:2 single-mode SC
-
Network functions:RSTP, VLAN and IGMP
-
PROFINET role:PROFINET IO device
-
Redundancy:Integrated redundancy manager
-
Configuration storage:C-PLUG supplied
-
Local diagnostics:LED indications and Select/Set pushbutton
-
External alarm:Error signaling contact
-
Supply range:18 to 32 V DC
-
Maximum current:0.4 A
-
Power connection:4-pole terminal block
-
Operating class:Managed Layer 2 industrial Ethernet
-
Lifecycle note:Phase-out announced 30 December 2023
Information
Overview
Manuals
Common Applications
Product Precautions
In a resilient plant network, Siemens 6GK5308-2FM10-2AA3 coordinates copper and long-distance single-mode fiber segments while retaining managed switching and ring-control functions.
- Eight copper ports combine seven Fast Ethernet paths with one gigabit-capable RJ45 path.
- Two 1000 Mbit/s single-mode SC ports support the documented long-distance optical uplinks.
- RSTP, VLAN and IGMP functions provide managed traffic control for the installed topology.
- The supplied C-PLUG retains the approved device configuration for controlled replacement.
Commissioning ties the stored C-PLUG configuration, PROFINET device assignment, signaling contact and redundancy role to the two optical paths and eight copper interfaces.
Important Notice: match the X308-2LD article number, SC fiber type, C-PLUG record and configured ring position before replacement.
Siemens 6GK5308-2FM10-2AA3 Manuals & Downloads
Siemens 6GK5308-2FM10-2AA3 Technical Reference (PDF)Siemens 6GK5308-2FM10-2AA3 Installation & Commissioning Guide (PDF)
The first document organizes exact technical resources and interface decisions; the second provides a separate field sequence for readiness, installation, verification and handover.
Fiber-linked control cells
Connects separated automation areas through two single-mode gigabit SC routes.
Managed plant backbones
Segments copper devices with VLAN and monitored switching functions.
Redundant Ethernet rings
Operates in the assigned ring role with the integrated redundancy manager.
PROFINET infrastructure
Presents the configured switch as a PROFINET IO device for diagnostic visibility.
Apply these checks to the exact Siemens 6GK5308-2FM10-2AA3 installation before isolation, replacement or release.
1
Confirm the complete 6GK5308-2FM10-2AA3 marking and X308-2LD identity before work.
2
Export the active configuration and record the installed C-PLUG before isolation.
3
Label all seven Fast Ethernet ports, the gigabit RJ45 port and both SC fiber routes.
4
Verify that each optical path uses the retained single-mode SC connection.
5
Prove both 18-32 V DC supply paths and the signaling-contact circuit safe.
6
Restore the ring-manager role, VLAN, RSTP, IGMP and PROFINET assignments.
7
Compare LED states and the error signaling contact after energization.
8
Test copper forwarding, both fiber uplinks and redundancy recovery before release.
Technical notes
Retain the C-PLUG configuration, single-mode SC assignments, signaling contact and network-management settings. After replacement, prove all eight copper interfaces, both fiber uplinks and redundancy recovery under the approved maintenance plan.
FAQ View All FAQ
-
How many copper ports does Siemens 6GK5308-2FM10-2AA3 provide?It provides seven 10/100 Mbit/s RJ45 ports and one 10/100/1000 Mbit/s RJ45 port.
-
Which fiber interfaces are fitted to Siemens 6GK5308-2FM10-2AA3?Two 1000 Mbit/s single-mode SC ports form the optical interface set.
-
Which managed network functions are available on Siemens 6GK5308-2FM10-2AA3?The product record includes RSTP, VLAN, IGMP, network management and an integrated redundancy manager.
-
Does Siemens 6GK5308-2FM10-2AA3 operate as a PROFINET device?Yes. The switch includes a PROFINET IO device role for the configured automation network.
-
What stores the configuration for Siemens 6GK5308-2FM10-2AA3?A C-PLUG is included for retaining and transferring the approved device configuration.
-
How is a fault reported by Siemens 6GK5308-2FM10-2AA3?Local LED diagnostics and an error signaling contact provide the two principal indication paths.
-
Which supply range applies to Siemens 6GK5308-2FM10-2AA3?The technical data sheet specifies an 18 to 32 V DC supply range through a four-pole terminal block.
-
What should be tested after installing Siemens 6GK5308-2FM10-2AA3?Verify every copper and fiber link, the alarm contact, PROFINET visibility and the configured redundancy recovery.
