      6DD1682-0CH0

      SIMATIC TDC UR5213 21-Slot Subrack

      Product Describe：

      Siemens 6DD1682-0CH0 receives the matched PS5213 power supply and coordinates power and backplane communication for installed processor, communication, and signal modules in high-performance automation systems.

      Ask our team:

      Get a quick price for： 6DD1682-0CH0
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Alternative names Technical notes FAQ

      Technical specifications for 6DD1682-0CH0

      Technical specifications for 6DD1682-0CH0

      • Manufacturer:
        Siemens
      • Product Category:
        DCS System
      • Spare Part Number:
        6DD1682-0CH0
      • Estimated shipping dimensions:
        34×16.1×29.5cm
      • Weight:
        2.6 kg
      • Tariff Code:
        8537101101
      • Counliy of origin:
        Germany
      • Subrack:
        UR5213
      • Slots:
        21
      • Input supply with matched PSU:
        90 to 264 V AC, 47 to 63 Hz
      • Documented DC rails:
        +5 V, +3.3 V, +12 V, -12 V
      • Power-failure backup:
        At least 15 ms
      • Protection:
        IP20; protection class I with PE
      • Operating temperature:
        0 to 55 degrees C
      • Dimensions:
        Approx. 482.6 × 354.9 × 343 mm — Siemens official published product data.
      • Approximate weight:
        20 kg
      • Weight:
        20 kg (44.092 lb) net weight — Siemens SiePortal for complete catalog number 6DD1682-0CH0.
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      The Siemens 6DD1682-0CH0 is the UR5213 subrack for SIMATIC TDC. It provides twenty-one module slots, the TDC backplane, mechanical support, power distribution, and the enclosure interfaces required by the configured control system.
      • UR5213
      • 21
      • 90 to 264 V AC, 47 to 63 Hz
      • +5 V, +3.3 V, +12 V, -12 V

      The rack receives the matched PS5213 power supply and coordinates power and backplane communication for installed processor, communication, and signal modules in high-performance automation systems.

      Important Notice: Use the complete 6DD1682-0CH0 code and verify the physical nameplate and current Siemens documentation before installation or replacement.

      Apter Power 6DD1682-0CH0 Manuals and Guides

      Important Notice: These are two separate Apter Power documents prepared from the manufacturer-published Siemens information named in each document. Confirm the physical nameplate, current Siemens documents, and host-system requirements before installation or replacement.

      Multi-processor TDC systems
      House coordinated CPU, communication, and I/O modules.
      Large drive-control cabinets
      Provide the mechanical and electrical system backbone.
      Process test stands
      Support dense real-time module configurations.
      Read and follow the exact Siemens documentation and host-equipment instructions before use. Verify 6DD1682-0CH0 from the physical nameplate.
      1
      Connect protective earth as specified before energization
      2
      Check total module loading against every supply rail
      3
      Maintain cabinet airflow and clearances
      4
      Use the approved slot plan and blanking arrangements
      5
      Remove power before inserting or removing modules

      Alternative Names

      Alternative Names

      6DD1682-0CH0 6DD1682 0CH0 Siemens 6DD1682-0CH0

      Technical notes

      Technical notes

      Use the complete 6DD1682-0CH0 identity. The current Siemens SIMATIC TDC hardware manual lists UR5213 article 6DD1682-0CH0. Confirm availability and module approvals for the exact system revision. Values not published in the cited Siemens source are intentionally not inferred.

      FAQS

      • What is Siemens 6DD1682-0CH0?
        The Siemens 6DD1682-0CH0 is the UR5213 subrack for SIMATIC TDC. It provides twenty-one module slots, the TDC backplane, mechanical support, power distribution, and the enclosure interfaces required by the configured control system.
      • What is the specific function of 6DD1682-0CH0?
        The rack receives the matched PS5213 power supply and coordinates power and backplane communication for installed processor, communication, and signal modules in high-performance automation systems.
      • Which signals, power, or data does 6DD1682-0CH0 handle?
        Subrack: UR5213. Slots: 21. Input supply with matched PSU: 90 to 264 V AC, 47 to 63 Hz. Documented DC rails: +5 V, +3.3 V, +12 V, -12 V.
      • Which system uses 6DD1682-0CH0?
        6DD1682-0CH0 belongs to the SIMATIC TDC context described in the cited Siemens source.
      • Which components are compatible with 6DD1682-0CH0?
        SIMATIC TDC modules permitted for the UR5213 slot plan PS5213 power supply article 6DD1683-0CH0 Cabinet cooling, PE, backplane, and EMC arrangement specified by Siemens
      • Where is 6DD1682-0CH0 applied?
        Multi-processor TDC systems: House coordinated CPU, communication, and I/O modules. Large drive-control cabinets: Provide the mechanical and electrical system backbone. Process test stands: Support dense real-time module configurations.
      • What is the lifecycle status of 6DD1682-0CH0?
        The current Siemens SIMATIC TDC hardware manual lists UR5213 article 6DD1682-0CH0. Confirm availability and module approvals for the exact system revision.
      • What must be checked before installing 6DD1682-0CH0?
        Connect protective earth as specified before energization Check total module loading against every supply rail Maintain cabinet airflow and clearances Use the approved slot plan and blanking arrangements Remove power before inserting or removing modules
