      6DD1682-0BE0

      SIMADYN D SR24.2 24-Slot Subrack

      Product Describe：

      Siemens 6DD1682-0BE0 forms the mechanical, power, and data backbone for an installed SIMADYN D control system and uses the SP9 power-supply type documented by Siemens.

      Ask our team:

      Get a quick price for： 6DD1682-0BE0
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Alternative names Technical notes FAQ

      Technical specifications for 6DD1682-0BE0

      Technical specifications for 6DD1682-0BE0

      • Manufacturer:
        Siemens
      • Product Category:
        DCS System
      • Spare Part Number:
        6DD1682-0BE0
      • Estimated shipping dimensions:
        54.2x32x51cm
      • Weight:
        7.46 kg
      • Tariff Code:
        8537101101
      • Counliy of origin:
        Germany
      • Subrack:
        SR24.2
      • Article:
        6DD1682-0BE0
      • Slots:
        24
      • Module format:
        233.4 x 220 mm
      • Input supply:
        24 V DC
      • Cooling:
        No integrated fan; cabinet self-convection requirements apply
      • Power-supply type:
        SP9
      • Backplanes:
        L bus and C bus
      • Weight:
        16.2 kg (35.715 lb) net weight — Siemens SiePortal for complete catalog number 6DD1682-0BE0.
      • Dimensions:
        Siemens SiePortal lists official packaging dimensions 63 × 62 × 43.8 cm (L × W × H). Exact device W × H × D is not stated; do not use packaging dimensions for mounting.
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      The Siemens 6DD1682-0BE0 is the SIMADYN D SR24.2 subrack. It accommodates twenty-four 233.4 x 220 mm modules, distributes power through its integrated supply, and carries control data over the L-bus and C-bus backplanes.
      • SR24.2
      • 6DD1682-0BE0
      • 24
      • 233.4 x 220 mm

      This fanless 24 V DC rack forms the mechanical, power, and data backbone for an installed SIMADYN D control system and uses the SP9 power-supply type documented by Siemens.

      Important Notice: Use the complete 6DD1682-0BE0 code and verify the physical nameplate and current Siemens documentation before installation or replacement.

      Apter Power 6DD1682-0BE0 Manuals and Guides

      Important Notice: These are two separate Apter Power documents prepared from the manufacturer-published Siemens information named in each document. Confirm the physical nameplate, current Siemens documents, and host-system requirements before installation or replacement.

      Large SIMADYN D systems
      House up to twenty-four coordinated modules.
      Drive and process cabinets
      Distribute rack power and L/C-bus communication.
      Fanless rack installations
      Use cabinet airflow designed for self-convection.
      Read and follow the exact Siemens documentation and host-equipment instructions before use. Verify 6DD1682-0BE0 from the physical nameplate.
      1
      Provide the Siemens-required cabinet cooling openings
      2
      Connect the rack to the grounding rail with the specified bonding conductor
      3
      Keep empty-slot covers and backplane jumpers correctly fitted
      4
      Check module current demand against the power supply
      5
      Back up configured values before disturbing the battery-backed system

      Alternative Names

      Alternative Names

      6DD1682-0BE0 6DD1682 0BE0 Siemens 6DD1682-0BE0

      Technical notes

      Technical notes

      Use the complete 6DD1682-0BE0 identity. SR24.2 belongs to the legacy SIMADYN D platform. Confirm current Siemens service options and the exact installed power-supply revision. Values not published in the cited Siemens source are intentionally not inferred.

      FAQS

      • What is Siemens 6DD1682-0BE0?
        The Siemens 6DD1682-0BE0 is the SIMADYN D SR24.2 subrack. It accommodates twenty-four 233.4 x 220 mm modules, distributes power through its integrated supply, and carries control data over the L-bus and C-bus backplanes.
      • What is the specific function of 6DD1682-0BE0?
        This fanless 24 V DC rack forms the mechanical, power, and data backbone for an installed SIMADYN D control system and uses the SP9 power-supply type documented by Siemens.
      • Which signals, power, or data does 6DD1682-0BE0 handle?
        Subrack: SR24.2. Article: 6DD1682-0BE0. Slots: 24. Module format: 233.4 x 220 mm.
      • Which system uses 6DD1682-0BE0?
        6DD1682-0BE0 belongs to the SIMADYN D context described in the cited Siemens source.
      • Which components are compatible with 6DD1682-0BE0?
        SIMADYN D modules permitted by the rack loading and slot rules SP9 power-supply arrangement documented for SR24.2 24 V DC source, cabinet cooling, grounding, battery, and backplane jumpers specified by Siemens
      • Where is 6DD1682-0BE0 applied?
        Large SIMADYN D systems: House up to twenty-four coordinated modules. Drive and process cabinets: Distribute rack power and L/C-bus communication. Fanless rack installations: Use cabinet airflow designed for self-convection.
      • What is the lifecycle status of 6DD1682-0BE0?
        SR24.2 belongs to the legacy SIMADYN D platform. Confirm current Siemens service options and the exact installed power-supply revision.
      • What must be checked before installing 6DD1682-0BE0?
        Provide the Siemens-required cabinet cooling openings Connect the rack to the grounding rail with the specified bonding conductor Keep empty-slot covers and backplane jumpers correctly fitted Check module current demand against the power supply Back up configured values before disturbing the battery-backed system
