What is ProSoft PLX31-EIP-MBS?

The ProSoft PLX31-EIP-MBS is an industrial gateway that enables high-speed, bi-directional data exchange between EtherNet/IP devices and Modbus serial devices. It is widely used to integrate different industrial protocols into one network.

What communication protocols does ProSoft PLX31-EIP-MBS support?

The module supports EtherNet/IP (CIP messaging) and Modbus RTU/ASCII serial protocols, allowing seamless communication between PLCs and Modbus devices. It also supports Class 1 and Class 3 connections.

What types of controllers are compatible with ProSoft PLX31-EIP-MBS?

It is compatible with EtherNet/IP controllers such as ControlLogix and CompactLogix, as well as other industrial controllers supporting Ethernet/IP. This makes it flexible for multi-vendor environments.

What is the power supply requirement for ProSoft PLX31-EIP-MBS?

The module operates on a 24 VDC nominal power supply, with an allowable range of 10 to 36 VDC. Typical current consumption is about 300 mA at 24 VDC.

How does ProSoft PLX31-EIP-MBS ensure reliable communication?

It features industrial-grade design, electrical isolation (up to 1500 Vrms Ethernet and 2500 Vrms serial), and advanced diagnostics like LED indicators and data analyzer tools.

PLX31-EIP-MBS

Name: PLX31-EIP-MBS
Brand: ProSoft

Gateway Ethernet/IP to Modbus Serial

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

PLX31EIPMBS
COMMUNICATION MODULE
ETHERNET/IP TO MODBUS
SERIAL GATEWAY
10-36VDC

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Warranty Policy

Review the applicable warranty coverage and claim process.
Return Notice

Check the return process and obtain approval before sending an item back.
Shipping Method

Review shipping arrangements, transit estimates and delivery responsibilities.
Parts Availability

Browse stock listings and confirm current availability with our team.
How to order

See how to submit an enquiry, review a quotation and confirm an order.

Get a quick price for PLX31-EIP-MBS

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for PLX31-EIP-MBS

Manufacturer:

ProSoft
Product Category:

PLC Systems
Estimated shipping dimensions:

5x12.5x14cm
Weight:

0.24 kg
Tariff Code:

8537101190
Counliy of origin:

USA
Category:

PLCs/Machine Control
Subcategory:

VDC Logic I/O Module
Backplane Current Load:

800 mA @ 5.1 VDC
Operating Temperature Range:

-40° C to 85° C
Storage Temperature Range:

-40° C to 185° F
Relative Humidity (non-condensing):

5% to 95%
Processor Compatibility:

Rockwell Automation SLC 5/02 M0/M1 capable processors or newer

Ask for Quote

Information

Overview Manuals Common Applications Application

The PLX31-EIP-MBS is an industrial gateway module that bridges EtherNet/IP networks with Modbus serial devices. It allows seamless data communication between PLCs and Modbus-enabled equipment, making it ideal for integrating heterogeneous control systems in industrial automation.

Mark VIe Wind
Conformal Coated I/O Board
Printed circuit board

The gateway supports high-speed bi-directional data exchange and features industrial-grade reliability, including electrical isolation, configurable baud rates, and diagnostic LEDs. It enables flexible system expansion and ensures stable communication across different automation networks.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

ProSoft PLX31-EIP-MBS Gateway Ethernet/IP to Modbus Serial Manuals, Datasheets, Drivers, Link

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

PLC Integration

Used to connect EtherNet/IP PLCs with Modbus serial devices, enabling seamless communication. Supports real-time data transfer for controlling and monitoring industrial processes.

Factory Automation

Applied in automated manufacturing systems to allow centralized monitoring and control of diverse equipment. Ensures data exchange between legacy Modbus devices and modern Ethernet-based controllers.

Remote Monitoring

Supports remote access to field devices over Ethernet, enabling diagnostics, configuration, and troubleshooting. Reduces the need for on-site visits and minimizes downtime.

Data Acquisition

Used to collect operational data from multiple Modbus devices and transfer it to Ethernet networks. Supports logging, reporting, and process optimization.

Multi-Vendor Networking

Enables integration of devices from different manufacturers into one Ethernet network. Bridges communication gaps between modern and legacy devices.

Industrial Control Systems

Used in industries such as oil & gas, water treatment, and manufacturing plants for reliable device communication. Supports process control, system supervision, and alarm management.

The PLX31-EIP-MBS enables integration of EtherNet/IP networks with Modbus serial devices in industries such as manufacturing, water treatment, and oil & gas. It allows real-time monitoring, data acquisition, and control, providing reliable communication between PLCs and field devices.

Its design supports multi-vendor environments, bridging communication gaps between legacy Modbus equipment and modern Ethernet-enabled controllers. This facilitates centralized system management, reduces network complexity, and allows for scalable automation solutions.

FAQ View All FAQ

What is ProSoft PLX31-EIP-MBS?

The ProSoft PLX31-EIP-MBS is an industrial gateway that enables high-speed, bi-directional data exchange between EtherNet/IP devices and Modbus serial devices. It is widely used to integrate different industrial protocols into one network.
What communication protocols does ProSoft PLX31-EIP-MBS support?

The module supports EtherNet/IP (CIP messaging) and Modbus RTU/ASCII serial protocols, allowing seamless communication between PLCs and Modbus devices. It also supports Class 1 and Class 3 connections.
What types of controllers are compatible with ProSoft PLX31-EIP-MBS?

It is compatible with EtherNet/IP controllers such as ControlLogix and CompactLogix, as well as other industrial controllers supporting Ethernet/IP. This makes it flexible for multi-vendor environments.

What is the power supply requirement for ProSoft PLX31-EIP-MBS?

The module operates on a 24 VDC nominal power supply, with an allowable range of 10 to 36 VDC. Typical current consumption is about 300 mA at 24 VDC.
How does ProSoft PLX31-EIP-MBS ensure reliable communication?

It features industrial-grade design, electrical isolation (up to 1500 Vrms Ethernet and 2500 Vrms serial), and advanced diagnostics like LED indicators and data analyzer tools.
