      P0916DB

      Termination Cable
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      P0916DB is a 1.0 m Type 1 P/PVC termination cable listed for Foxboro FBM220 and FBM221 FOUNDATION Fieldbus H1 termination assemblies.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for P0916DB
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for P0916DB

      • Manufacturer:
        Invensys
      • Product Category:
        DCS Systems
      • Spare Part Number:
        P0916DB
      • Estimated shipping dimensions:
        4.5x12.3x11.5cm
      • Weight:
        0.25 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product type:
        Termination cable
      • Cable type:
        Type 1
      • Cable material:
        P/PVC
      • Length:
        1.0 m (3.2 ft)
      • Associated modules:
        FBM220 / FBM221
      • Signal family:
        FOUNDATION Fieldbus H1
      • P/PVC temperature range:
        -20 to +80 deg C
      • Module role:
        Connection to selected termination assembly
      • Network rate:
        31.25 kbps H1 at field side
      • Module Fieldbus:
        Redundant 2 Mbps at FBM side
      • Installation control:
        Match FBM, TA and segment record
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Foxboro P0916DB carries the documented module-to-termination connection for an FBM220 or FBM221 H1 interface while retaining the Type 1 connector and environmental execution.
      • 1.0 m cable length
      • Type 1 termination cable
      • P/PVC construction
      • FBM220 / FBM221 application

      The cable is selected together with the FBM type and compatible H1 termination assembly. Both ends, routing, shield practice and minimum bend control must remain traceable to the exact fieldbus segment.

      Important Notice: P0916DB is a termination cable, not a Fieldbus Module or termination assembly. Confirm the 1.0 m Type 1 P/PVC entry before installation.

      Foxboro P0916DB Manuals & Downloads
      Foxboro P0916DB Technical Reference (PDF)Foxboro P0916DB Manufacturer Manual Excerpt (PDF)

      The technical reference organizes exact characteristics and engineering boundaries. The manufacturer excerpt presents selected unchanged official pages used for exact-model review.

      Single-segment FBM220 links
      Connects the module to its selected H1 termination assembly.
      Four-segment FBM221 links
      Supports the documented cable entry for the multi-segment interface.
      Short cabinet interconnections
      Provides a one-metre module-to-TA route.
      Exact cable replacement
      Restores the P0916DB Type 1 P/PVC execution without changing segment design.
      Foxboro P0916DB installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Confirm P0916DB, Type 1 and 1.0 m on the cable record.
      2
      Record the FBM220 or FBM221 and associated TA part number.
      3
      Place all affected FOUNDATION Fieldbus segments in the safe state.
      4
      Isolate segment and module power according to the approved procedure.
      5
      Label both cable ends and every affected H1 segment.
      6
      Protect connectors, jacket and bend radius during routing.
      7
      Do not substitute a different length or insulation family without review.
      8
      Verify segment power, communications and every field device before release.

      Technical notes

      For P0916DB, retain the exact manufacturer identity, installed connection record and witnessed model-specific acceptance result.

      FAQ View All FAQ

      • What kind of product is Foxboro P0916DB?
        It is a termination cable rather than a module or termination assembly.
      • Which cable type applies to Foxboro P0916DB?
        The manufacturer cable table identifies it as Type 1.
      • Which material is used for Foxboro P0916DB?
        It uses the listed P/PVC cable construction.
      • How long is Foxboro P0916DB?
        Its documented length is 1.0 metre, or 3.2 feet.
      • Which modules are associated with Foxboro P0916DB?
        The cable is listed in the FBM220 and FBM221 FOUNDATION Fieldbus H1 product specification.
      • Which temperature range is stated for Foxboro P0916DB P/PVC cable?
        The table lists -20 to +80 degrees Celsius for the P/PVC cable execution.
      • Why must both cable ends be recorded for Foxboro P0916DB?
        The cable links a specific FBM port to a selected H1 termination assembly and segment.
      • What completes commissioning of Foxboro P0916DB?
        Confirm connector seating and segment power, then verify communications with every expected FOUNDATION Fieldbus device.
