Honeywell CC-PCF901 Nine-Port Control Firewall Module

Name: CC-PCF901
Brand: Honeywell
SKU: CC-PCF901

CC-PCF901

Nine-Port Control Firewall Module

In Stock

Ships by Monday, September 21

Fast Shipping Available

Technical specifications for CC-PCF901

Manufacturer:

Honeywell

Product Category:

Machinery Monitoring System

Spare Part Number:

CC-PCF901

Estimated shipping dimensions:

5.5x16.2x14.5cm

Weight:

0.32 kg

Tariff Code:

8537101190

Counliy of origin:

USA

Module role:

Control Firewall

Network ports:

IOTA:

CC-TCF901

Supply:

24 V DC

Current:

0.150 A

Heat dissipation:

3.750 W

Information

Overview Manuals Common Applications Product Precautions

Honeywell CC-PCF901 is nine-port control firewall module. It provides the nine-port control-firewall interface used to connect a C300 controller arrangement to its documented FTE control network.

Provides nine control-network ports
Pairs with the CC-TCF901 firewall IOTA
Occupies the UHIO/C300 control-network position
Supports controlled FTE path diagnostics

CC-PCF901 operates with CC-TCF901 IOTA, C300 controller, FTE network switches and cables, Experion topology and node record.

Engineered applications include C300 FTE cabinet connection, Redundant controller network service, Control-network migration, Firewall-module replacement.

Important Notice: Verify the CC-TCF901 IOTA, port labels, FTE A/B paths, cable routing, controller pairing and approved firmware record before returning the node to service.

Apter Power CC-PCF901 Manuals and Guides

Apter Power CC-PCF901 Product and System Technical Reference PDF Apter Power CC-PCF901 Field Installation and Functional Acceptance Workbook PDF

The first document organizes model-specific identity, technical data and system context. The second provides a separate installation, connection, commissioning and acceptance workflow.

C300 FTE cabinet connection

Terminates the controller network at the Series-C cabinet.

Redundant controller network service

Maintains the documented redundant network arrangement.

Control-network migration

Supports phased control-network hardware renewal.

Firewall-module replacement

Restores a failed network interface with its port identities preserved.

Read the applicable Honeywell instructions before work. Verify CC-PCF901 and the installed Experion C300 control network configuration.

Verify the complete CC-PCF901 marking and its assigned nine-port Control Firewall position before work.

Place the connected process and control strategy in the approved maintenance state.

Isolate the applicable cabinet supply and network field energy before disconnecting conductors.

Record terminal numbers, channel assignments, polarity, shields and configured ranges before removal.

Use ESD controls and protect the backplane connector, terminal hardware and coated electronics.

Confirm the installed CC-TCF901 IOTA and carrier arrangement against the approved project.

Restore power in a controlled sequence and clear only diagnostics created by the maintenance activity.

Complete FTE path, link-status and controller communication checks and retain the measured result before returning the channel to automatic service.

FAQS

What exact Honeywell system position is intended for CC-PCF901?

CC-PCF901 is assigned to the documented Experion C300 control network role as nine-port control firewall module; confirm that role against the installed cabinet record.
Which field signal or controlled function is handled by CC-PCF901?

Its documented signal duty is experion fault tolerant ethernet control-network traffic. The controlling source lists network ports as 9.
Which companion hardware must be checked before installing CC-PCF901?

Match CC-PCF901 with CC-TCF901 IOTA and C300 controller; also retain the approved carrier, cable and project identity.
What electrical limit should an engineer verify before wiring CC-PCF901?

Verify the model-specific value for Supply: 24 V DC. Do not transfer a limit from another module revision.
How should the installed configuration be preserved when replacing CC-PCF901?

Record the as-found slot, connector, channel assignment and project revision, then restore only the approved Experion C300 control network configuration.
Which isolation or handling check applies to CC-PCF901?

Apply the isolation and ESD sequence stated for CC-PCF901; the source also identifies heat dissipation as 3.750 W.
What diagnostic or commissioning evidence is required for CC-PCF901?

Complete the model-specific functional check for c300 fte cabinet connection, review host diagnostics and retain the final test result.
Can CC-PCF901 be substituted for a visually similar Honeywell assembly?

No automatic substitution is assumed. Compare the complete CC-PCF901 marking, module role, companion hardware, signal duty and approved system revision.
