Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for CC-PAIM01
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for CC-PAIM01
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:51405045-175
-
Estimated shipping dimensions:6x15.5x14.5cm
-
Weight:0.38 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Input type:Thermocouple and/or RTD
-
Input channels:64
-
Input scan rate:1 second
-
Channel bandwidth:0 to 4.7 Hz
-
TC input range:-20 to +100 mV
-
RTD excitation current:1 mA
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell CC-PAIM01 is a Series-C low-level analog temperature-input multiplexer for thermocouple and RTD measurements.
- Thermocouple and RTD measurement capability
- Remote cold-junction support
- Open-thermocouple detection processing
- PMIO low-level multiplexer FTA integration
CC-PAIM01 uses the documented PMIO LLMUX FTA family so the installed thermocouple, millivolt and RTD point mix can be configured for the Series-C system.
Important Notice: Verify the selected FTA, sensor type, cold-junction arrangement, terminal wiring and configured channel mapping before commissioning.
Apter Power CC-PAIM01 Manuals and Guides
Important Notice: These are two distinct Apter Power documents: the first is a product technical reference, while the second supports installation planning, application review and commissioning verification.
CC-PAIM01 Installed-base maintenance
Like-for-like service planning for documented Series-C temperature-input assemblies.
CC-PAIM01 Compatibility review
Comparison of the FTA, sensor family, cold-junction arrangement and channel configuration.
CC-PAIM01 Installation planning
Preparation of sensor, shield, terminal and reference-junction checks before field work.
CC-PAIM01 Commissioning
Controlled verification of readings, diagnostics and configured measurement response.
二个Read the applicable Honeywell installation instructions before work. Verify CC-PAIM01 and the installed-system configuration.
1
Verify CC-PAIM01 and the complete part number on the physical nameplate before installation.
2
Confirm the installed Series-C carrier, FTA and sensor arrangement support the intended measurement.
3
Isolate applicable power and field energy before removing or installing CC-PAIM01.
4
Use ESD controls and protect the carrier connectors, terminals and multiplexer assembly.
5
Record sensor wiring, shielding and channel configuration before replacement.
6
Do not transfer sensor or terminal assignments from an unrelated Honeywell I/O assembly.
7
Dress and identify sensor wiring to the applicable cabinet and terminal instructions.
8
After installation, test diagnostics, channel readings and intended process response.
Alternative Names
51405045-175
Technical notes
CC-PAIM01 is a Series-C low-level analog temperature-input multiplexer for thermocouple and RTD measurements. Confirm sensor type, channel range, lead wiring, shielding, grounding and diagnostic status during installation and verification.
FAQ View All FAQ
-
What is CC-PAIM01 used for?CC-PAIM01 is a Series-C low-level analog temperature-input multiplexer for thermocouple and RTD measurements.
-
Which sensor types are used with CC-PAIM01?CC-PAIM01 is applied with the thermocouple or RTD sensor type documented for each configured channel.
-
Which installed hardware should be checked for CC-PAIM01?Confirm the Series-C location, compatible termination arrangement and approved sensor wiring before installation.
-
How should CC-PAIM01 be installed?Isolate the affected equipment, confirm module orientation and mount CC-PAIM01 in the documented Series-C position.
-
What wiring checks are required for CC-PAIM01?Verify sensor type, lead identification, polarity where applicable, shielding, grounding and channel mapping.
-
How should CC-PAIM01 be commissioned?Verify stable and reasonable temperature readings, channel diagnostics, alarms and dependent control functions.
-
What should be checked before replacing CC-PAIM01?Compare the complete CC-PAIM01 marking, installed configuration, sensor types and all channel terminations.
-
Which documents should be used for CC-PAIM01 service?Use the project sensor schedule, wiring drawings, configured channel record, Honeywell Series-C instructions and the Apter Power guide.
