Get a quick price for 51402573-250
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 51402573-250
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:51402573-250
-
Estimated shipping dimensions:2.9x21x14cm
-
Weight:0.34 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Interface:UCN
-
Module function:HPM communication interface
-
Assembly:Module
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell 51402573-250 is a UCN interface module assembly for a High-Performance Process Manager. It provides the hardware communication path between the HPM and Universal Control Network.
- Connects the HPM to the Universal Control Network
- Transfers controller data over UCN
- Fits the HPM communication position
- Supports redundant network operation
51402573-250 installs with HPM controller, UCN A/B cabling, HPM communication control board, Controller cardfile in an engineered TDC 3000 High-Performance Process Manager configuration.
The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this ucn interface module assembly.
Important Notice: Confirm the complete 51402573-250 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.
Apter Power 51402573-250 Manuals and Guides
Apter Power 51402573-250 Product Technical Reference PDFApter Power 51402573-250 Installation and Verification PDFThe first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
HPM UCN communicationConnects the HPM to the Universal Control Network
Controller-node restorationTransfers controller data over UCN
Redundant network testingFits the HPM communication position
Legacy UCN maintenanceSupports redundant network operation
Read the applicable Honeywell installation instructions before work. Verify 51402573-250 and the installed TDC 3000 High-Performance Process Manager configuration.
1Verify the complete 51402573-250 marking and the assigned TDC 3000 High-Performance Process Manager position before field work.
2Isolate the applicable power, network and field energy before disconnecting 51402573-250.
3Use ESD controls and protect the keyed connectors of 51402573-250 during handling.
4Record the installed wiring, jumpers, node or channel assignment before replacement.
5Confirm HPM controller and UCN A/B cabling against the approved system configuration.
6Restore 51402573-250 under controlled conditions and review the product-specific diagnostics.
7Complete a functional test for hpm ucn communication before production release.
Technical notes
Keep UCN A and B paths identified, record the installed module position and confirm controller visibility on both network channels.
FAQ View All FAQ
-
Which HPM controller identity must be verified before fitting the 51402573-250 UCN Interface Module Assembly?Match the complete 51402573-250 marking, assigned TDC 3000 High-Performance Process Manager position and installed HPM controller before work.
-
How should UCN A/B cabling be isolated before disconnecting the 51402573-250 UCN Interface Module Assembly?Place the affected process in its approved maintenance state, isolate applicable energy and prove UCN A/B cabling safe before disconnection.
-
What as-found wiring record is required for the 51402573-250 UCN Interface Module Assembly in HPM UCN communication?Record terminal identity, polarity, shields, jumpers, cable tags and the as-found diagnostic state for 51402573-250.
-
Which TDC 3000 High-Performance Process Manager configuration must be checked when commissioning the 51402573-250 UCN Interface Module Assembly?Verify the assigned channel, slot, node or interface and compare it with the approved TDC 3000 High-Performance Process Manager configuration before enabling 51402573-250.
-
How can the 51402573-250 UCN Interface Module Assembly be function-tested for Controller-node restoration without disturbing the process?Use a controlled stimulus or limited command, observe the expected system indication and confirm the intended response while normal interlocks remain effective.
-
Which diagnostics should be reviewed if the 51402573-250 UCN Interface Module Assembly stops performing its assigned system function?Check seating, the matched HPM controller, the condition of UCN A/B cabling and the model-specific diagnostics before replacing more hardware.
-
Can the 51402573-250 UCN Interface Module Assembly used for Redundant network testing be transferred to another TDC 3000 High-Performance Process Manager position without engineering review?No. Confirm the hardware execution, connector scheme and approved TDC 3000 High-Performance Process Manager configuration before transferring 51402573-250 to a different duty.
-
What evidence should be retained after the 51402573-250 UCN Interface Module Assembly returns to Legacy UCN maintenance service?Retain the physical identification, as-left wiring or configuration, final diagnostics and controlled functional-test result for 51402573-250.
