What is HIMA BV7032-0.5?

HIMA BV7032-0.5 is the 0.5 m execution of the BV 7032 flat data connecting cable used on the documented HIQuad I/O bus.

What cable length does HIMA BV7032-0.5 specify?

The exact execution specifies a cable length of 0.5 m.

Where is HIMA BV7032-0.5 used in a B 9302 rack arrangement?

It is used to connect the H51q I/O bus to a B 9302 I/O rack and to continue the bus between documented I/O racks.

Which I/O-rack interfaces are used with HIMA BV7032-0.5?

The HIMA B 9302 sheet identifies XD.1 and XD.2 as the I/O-bus connections for the central-rack and onward-rack path.

What maximum total bus length applies when HIMA BV7032-0.5 is installed?

HIMA states a maximum total I/O-bus length of 30 m for the documented rack arrangement.

How is the final rack terminated when HIMA BV7032-0.5 is used?

The HIMA central-rack data sheet instructs that the F 7546 bus termination module be fitted at XD.2 of the last I/O rack.

Can a 1 m BV 7032 cable automatically replace HIMA BV7032-0.5?

No. The 0.5 m and 1 m versions are separate documented executions, and any change must preserve the approved rack route and total bus length.

What must be checked before releasing HIMA BV7032-0.5 to service?

Confirm the exact length, connector seating, XD.1/XD.2 rack sequence, final F 7546 termination, total bus length and normal rack diagnostics.

BV7032-0.5

Name: BV7032-0.5
Brand: HIMA
SKU: BV7032-0.5

I/O Bus Cable

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

HIMA BV7032-0.5 is the 0.5 m execution of the BV 7032 flat data connecting cable for the HIQuad I/O bus. HIMA documents it in B 9302 rack assemblies and H51q central-to-I/O-rack bus wiring.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for BV7032-0.5

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for BV7032-0.5

Manufacturer:

HIMA
Product Category:

DCS Systems
Spare Part Number:

BV7032-0.5
Estimated shipping dimensions:

5x59x6.7x2cm
Weight:

0.1 kg
Tariff Code:

8537101190
Counliy of origin:

Germany
Manufacturer notation:

BV 7032
Product form:

Flat data connecting cable
Exact cable length:

0.5 m
System family:

HIQuad H51q
Bus function:

I/O bus data connection
Rack application:

B 9302 I/O rack
Central-rack application:

B 5233 H51q-HS / H51q-HRS
I/O-rack interfaces:

XD.1 and XD.2
Documented bus arrangements:

Single or redundant I/O bus
Maximum total bus length:

30 m
Termination boundary:

F 7546 at the last I/O rack

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

The BV7032-0.5 provides the short flat-cable link used to extend the documented H51q I/O bus between the central rack and B 9302 I/O racks.

Confirm the complete BV7032-0.5 identity and 0.5 m execution.
Route the cable only through the documented H51q I/O-bus interfaces.
Preserve the XD.1/XD.2 rack sequence and the last-rack bus termination.
Keep the total installed I/O-bus length within the documented 30 m maximum.

BV7032-0.5 is a passive data connection within the HIQuad rack architecture. The installed single- or redundant-bus drawing determines which central-rack connector, first I/O rack and onward rack sequence must be restored.

Important Notice: BV7032-0.5 is a 0.5 m I/O-bus data cable, not an analog module or controller. Do not substitute another BV cable or length without confirming the rack topology and total bus length.

HIMA BV7032-0.5 Manuals & Downloads

HIMA BV7032-0.5 Manufacturer Manual Excerpt (PDF)HIMA BV7032-0.5 Installation & Commissioning Guide (PDF)

The manufacturer excerpt preserves the relevant original HIMA pages without external web links. The installation guide organizes controlled replacement, wiring or network checks, commissioning and acceptance.

Central-to-I/O-rack link

Connect the documented H51q central-rack I/O bus to XD.1 of the first B 9302 rack.

I/O-rack continuation

Continue the I/O bus from XD.2 to the next documented B 9302 rack.

Redundant bus path

Provide the exact 0.5 m cable on either approved path of an H51q-HRS redundant I/O-bus arrangement.

Controlled cable replacement

Restore the rack order, connector seating and final F 7546 termination without changing the engineered topology.

HIMA BV7032-0.5 installation checks: preserve the exact model identity, documented system arrangement and controlled acceptance evidence.

Verify the full BV7032-0.5 marking and measured 0.5 m execution before installation.

Record the central-rack connector, I/O-rack order and current termination position before disconnection.

Apply the approved system shutdown and electrostatic-control procedure before opening the rack interfaces.

Protect the flat cable and connector bodies from twisting, crushing, contamination and contact damage.

Reconnect the first I/O rack at XD.1 and use XD.2 only for the documented onward bus path.

Confirm the F 7546 bus termination remains at the last I/O rack in each installed bus path.

Check the complete bus route against the 30 m maximum and the approved single- or redundant-bus drawing.

Review rack diagnostics and witness normal I/O communication before returning the system to service.

Technical notes

Record the H51q bus path, XD.1/XD.2 sequence, connector condition and final F 7546 termination before replacing BV7032-0.5.
