      IC697CMM742

      Series 90-70 TCP/IP Ethernet Interface (Type 2)
      In Stock
      Ships by Thursday, November 12
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      GE IC697CMM742 is a Series 90-70 TCP/IP Ethernet Interface Type 2 module. It exchanges controller data and service traffic between a Series 90-70 rack and the configured Ethernet network.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for IC697CMM742
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for IC697CMM742

      • Manufacturer:
        General Electric
      • Product Category:
        General Automation
      • Spare Part Number:
        IC697CMM742
      • Estimated shipping dimensions:
        4x21.8x29.1cm
      • Weight:
        0.48 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • PLC platform:
        Series 90-70
      • Interface type:
        TCP/IP Ethernet Interface Type 2
      • Ethernet ports:
        10Base-T; 10Base2; AUI
      • Station Manager port:
        RS-232
      • Software-load port:
        RS-485
      • Network protocol:
        TCP/IP
      • Service protocol:
        SRTP
      • Front indicators:
        MODULE OK; LAN ONLINE; SERIAL ACTIVE; STATUS
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      GE IC697CMM742 is a Series 90-70 TCP/IP Ethernet Interface Type 2 module. It exchanges controller data and service traffic between a Series 90-70 rack and the configured Ethernet network.
      • Connects a Series 90-70 PLC rack to an Ethernet network
      • Provides station-management access through the serial service interface
      • Exchanges PLC data through the documented TCP/IP communication services
      • Reports module, network and serial activity through dedicated front indicators

      IC697CMM742 installs with Series 90-70 PLC rack, 10Base-T, 10Base2 or AUI network connection, RS-232 Station Manager cable, RS-485 software-load connection in an engineered Series 90-70 Ethernet communications configuration.

      The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this series 90-70 tcp/ip ethernet interface (type 2).

      Important Notice: Confirm the complete IC697CMM742 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.

      Apter Power IC697CMM742 Manuals and Guides
      Apter Power IC697CMM742 TCP/IP Interface Engineering BriefApter Power IC697CMM742 Network Setup & Diagnostic Workbook
      The first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
      Legacy PLC Ethernet integrationConnects a Series 90-70 PLC rack to an Ethernet network
      SCADA data exchange with Series 90-70 controllersProvides station-management access through the serial service interface
      Station Manager diagnosticsExchanges PLC data through the documented TCP/IP communication services
      Controlled network migration assessmentReports module, network and serial activity through dedicated front indicators
      Read the applicable GE installation instructions before work. Verify IC697CMM742 and the installed Series 90-70 Ethernet communications configuration.
      1Verify the complete IC697CMM742 marking and Type 2 hardware revision before service.
      2Place the Series 90-70 controller and networked process in the approved maintenance state.
      3Isolate rack and network energy before disconnecting the Ethernet or serial connectors.
      4Record the IP plan, SRTP channels, Station Manager settings and cable type before replacement.
      5Use ESD controls and protect the RJ-45, BNC, AUI and serial connectors.
      6Connect only one approved Ethernet path unless the project explicitly defines the topology.
      7Confirm MODULE OK, LAN ONLINE, SERIAL ACTIVE and STATUS indications during checkout.
      8Test programmer, SCADA and controller data paths before returning the network to service.

      Technical notes

      Insert IC697CMM742 in the documented Series 90-70 rack position, select one approved Ethernet port and record the network identity before configuring SRTP clients.

      FAQ View All FAQ

      • Which rack hosts IC697CMM742?
        IC697CMM742 is installed in a Series 90-70 PLC rack; confirm the assigned slot and CPU firmware/project compatibility before insertion.
      • Which physical Ethernet ports are available on IC697CMM742?
        The documented Type 2 interface provides 10Base-T, 10Base2 and AUI Ethernet connection options; the engineered network uses the approved one.
      • What is the purpose of the IC697CMM742 Station Manager port?
        The RS-232 Station Manager port provides the serial service path used for network setup, diagnostics and maintenance procedures.
      • Which port is used for software loading on IC697CMM742?
        The RS-485 software-load port is the documented serial connection for the module software-loader procedure.
      • What network settings should be captured before replacing IC697CMM742?
        Capture the IP identity, subnet plan, SRTP channels, station-management settings, selected Ethernet port and connected cable identifiers.
      • How do the IC697CMM742 indicators aid commissioning?
        MODULE OK, LAN ONLINE, SERIAL ACTIVE and STATUS provide the front-panel state evidence used with rack and network diagnostics during checkout.
      • Can all three IC697CMM742 Ethernet ports be used simultaneously?
        Use the Ethernet path defined by the approved topology; do not connect additional ports unless the project documentation explicitly permits that arrangement.
      • What test completes an IC697CMM742 replacement?
        Confirm rack recognition and indicators, then prove the configured programmer, SCADA and controller data paths with controlled traffic and recorded diagnostics.
