Technical specifications for IC660CBB902
-
Manufacturer:General Electric
-
Product Category:PLC Systems
-
Spare Part Number:IC660CBB902
-
Estimated shipping dimensions:3x26x31.6cm
-
Weight:0.58 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Complete model:IC660CBB902
-
Product type:Series Six Genius I/O bus controller with diagnostics
-
Hardware generation:Phase B
-
Network:Genius serial bus
-
Documented Phase B features:Programmed communications and redundancy support
-
Extended device support:RTD blocks and Genius blocks with more than 64 input or output bits
-
Direct field channels:None; determined by connected Genius I/O blocks
Information
Overview
Manuals
Common Applications
Product Precautions
The GE Fanuc IC660CBB902 is a Phase B Genius I/O bus controller with diagnostics for a Series Six programmable controller. It links the Series Six PLC to a Genius serial bus and coordinates cyclic I/O, device diagnostics and supported datagram communications.
- IC660CBB902
- Series Six Genius I/O bus controller with diagnostics
- Phase B
- Genius serial bus
Installed in a compatible Series Six rack, the controller scans Genius I/O devices, transfers input data to the PLC and sends output data from the PLC to the bus. Phase B operation also supports programmed communications and documented redundancy arrangements. It is a communications controller; the attached Genius blocks determine the physical discrete, analog or RTD signal characteristics.
Important Notice: Keep the complete IC660CBB902 marking unchanged and verify the physical nameplate, revision, companion hardware, and current manufacturer documentation before installation or replacement.
Apter Power IC660CBB902 Manuals and Guides
- Apter Power IC660CBB902 Product Reference Manual
- Apter Power IC660CBB902 Installation and Verification Reference
Important Notice: These are two separate Apter Power documents prepared from the manufacturer evidence named in each document. Confirm the physical nameplate, current manufacturer documentation, and applicable installation or system drawing before installation or replacement.
Control System Integration
Legacy Series Six automation systems with distributed Genius I/O, including process skids, utility systems, material handling and installations requiring CPU communications or supported bus redundancy.
Signal and Data Handling
Genius serial-bus I/O data, device diagnostics and supported programmed communications. Field signal voltage, current and sensor type are defined by each connected Genius I/O block.
Companion Hardware
Series Six CPU and compatible rack, Genius I/O serial bus, Genius I/O blocks, approved bus cable and terminating resistors, and a compatible Hand-held Monitor for setup and diagnostics.
Commissioning and Verification
Use IC660CBB902 only after confirming its complete nameplate, revision, configuration, connections, and every affected system function.
Read and follow the named manufacturer source and applicable installation instructions before use. Verify the exact complete ordering code from the physical nameplate.
1
Match the complete IC660CBB902 revision and Series Six CPU/software compatibility before installation.
2
Keep bus data rate, cable type, total length, termination and device addresses consistent with the approved Genius network design.
3
Do not apply field ratings from the bus controller to an I/O point; verify the individual Genius block manual.
4
Observe the applicable wiring, grounding, approval, environmental and enclosure requirements.
5
Record the complete model, revision, configuration and commissioning results before returning the system to service.
Revisions
Revision Part #
Also known as
Alternative Names
1C660CBB902
1C66OC889O2
IC660C88902
IC660C8B902
IC660CB8902
IC660CBB9O2
IC66OCBB902
IC66OCBB9O2
Technical notes
Only information traceable to the named manufacturer publications is stated. Missing electrical, dimensional, lifecycle, origin, weight or exact-revision compatibility values are intentionally not inferred. Confirm the complete physical nameplate, revision, approvals, wiring and current manufacturer documentation before use.
FAQ View All FAQ
-
What is GE Fanuc Automation IC660CBB902?The GE Fanuc IC660CBB902 is a Phase B Genius I/O bus controller with diagnostics for a Series Six programmable controller. It links the Series Six PLC to a Genius serial bus and coordinates cyclic I/O, device diagnostics and supported datagram communications.
-
What is the system function of IC660CBB902?Installed in a compatible Series Six rack, the controller scans Genius I/O devices, transfers input data to the PLC and sends output data from the PLC to the bus. Phase B operation also supports programmed communications and documented redundancy arrangements. It is a communications controller; the attached Genius blocks determine the physical discrete, analog or RTD signal characteristics.
-
What signals or data does IC660CBB902 handle?Genius serial-bus I/O data, device diagnostics and supported programmed communications. Field signal voltage, current and sensor type are defined by each connected Genius I/O block.
-
Which components are used with IC660CBB902?Series Six CPU and compatible rack, Genius I/O serial bus, Genius I/O blocks, approved bus cable and terminating resistors, and a compatible Hand-held Monitor for setup and diagnostics.
-
Where is IC660CBB902 commonly applied?Legacy Series Six automation systems with distributed Genius I/O, including process skids, utility systems, material handling and installations requiring CPU communications or supported bus redundancy.
-
Can IC660CBB902 be selected from the model number alone?No. Verify the complete IC660CBB902 physical nameplate, revision and the applicable manufacturer document before selection.
-
Are related family models automatic substitutes for IC660CBB902?No. A related family member, revision or modernization kit is not an unconditional drop-in replacement.
-
Can IC660CBB902 be replaced while the system is energized?No hot-swap claim is made here. Follow the manufacturer instructions and site isolation, electrical-safety and ESD procedures.
-
What should be checked after installing IC660CBB902?Verify identity, mounting, wiring or network connections, configuration, diagnostics and every affected control, I/O or safety function before release.
