Get a quick price for IC697MDL940
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for IC697MDL940
-
Manufacturer:General Electric
-
Product Category:PLC Systems
-
Spare Part Number:IC697MDL940
-
Estimated shipping dimensions:4x22x29.1cm
-
Weight:0.66 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Output points:16
-
Relay configuration:Eight isolated Form C; two groups of four Form A
-
Load voltage:24 to 240 V AC; 5 to 125 V DC
-
Point current:2 A at 120/240 V AC or 24 V DC
-
125 VDC point current:0.2 A
-
Module current:16 A maximum
-
Protection:RC snubber and fuse per point
-
Field terminal:Removable
Information
Overview
Manuals
Common Applications
Product Precautions
IC697MDL940 provides the documented series 90-70 relay output module role for a matched Series 90-70 PLC installation.
- Provides the documented series 90-70 relay output module function
- Uses exact catalog identity IC697MDL940 for replacement control
- Integrates with the matched Series 90-70 PLC hardware
- Supports controlled connection checks and functional verification
The component is used with the exact terminal assembly, carrier, power grouping and bus configuration identified for IC697MDL940. Commissioning preserves the installed point map and verifies controlled field response.
Important Notice: Confirm IC697MDL940, Series 90-70 PLC host, hardware revision, terminal or connector type, power and signal ranges, wiring, grounding, bus configuration, companion accessories and controlled commissioning results before service release.
Apter Power IC697MDL940 Manuals and Guides
- Apter Power IC697MDL940 Technical Data and System Reference PDF
- Apter Power IC697MDL940 Installation, Wiring and Acceptance Workbook PDF
Use these Apter Power reference materials with current manufacturer instructions and installed-system records. Confirm model, document revision and scope; a guide or blank workbook is not evidence that the offered unit has passed inspection.
Series 90-70 PLC station maintenance
Restores the documented series 90-70 relay output module function in an engineered station.
Distributed I/O refurbishment
Uses exact IC697MDL940 identity when rebuilding the recorded field interface.
Control-panel modernization
Preserves the approved terminal, power and communications arrangement during migration work.
Controlled recommissioning
Verifies point mapping, diagnostics and field response before process release.
Read the applicable General Electric installation instructions before work. Verify IC697MDL940, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
1
Confirm the full IC697MDL940 catalog marking and installed Series 90-70 PLC position before work.
2
Isolate the station supply and connected field energy using the approved procedure.
3
Record every terminal, common, shield, connector and configured point before removal.
4
Use ESD controls and protect backplane, terminal and connector contacts from contamination.
5
Verify each documented value for IC697MDL940 against the installed host and field circuit.
6
Restore the approved terminal assembly, power grouping and configuration record.
7
Energize in the prescribed sequence and review module, bus and point diagnostics.
8
Complete a controlled signal or load test before returning the station to service.
Technical notes
Install IC697MDL940 only in the documented Series 90-70 PLC position. Preserve the as-found terminal mapping and configuration, then verify diagnostics and the affected field function under controlled conditions.
FAQ View All FAQ
-
How is IC697MDL940 identified?Match the complete catalog number and the Series 90-70 Relay Output Module designation.
-
Which system accepts IC697MDL940?Use the documented Series 90-70 PLC carrier, terminal and bus arrangement.
-
What records are retained before removing IC697MDL940?Record terminals, commons, shields, connectors, point mapping and diagnostics.
-
How is IC697MDL940 isolated safely?Isolate station and field supplies, prove the safe state and apply ESD controls.
-
Which official values govern IC697MDL940?Output points: 16; Relay configuration: Eight isolated Form C; two groups of four Form A; Load voltage: 24 to 240 V AC; 5 to 125 V DC; Point current: 2 A at 120/240 V AC or 24 V DC.
-
How is IC697MDL940 configuration restored?Restore the approved hardware execution, power grouping and point map.
-
Which diagnostics follow IC697MDL940 energization?Review module, bus and channel status in the prescribed startup sequence.
-
What releases IC697MDL940 to service?A controlled signal or load test with the expected field response and no active diagnostic.
