Technical specifications for IC600BF843
-
Manufacturer:General Electric
-
Product Category:PLC Systems
-
Spare Part Number:IC600BF843L
-
Estimated shipping dimensions:2.5 cm x 27.9 cm x 22.9 cm
-
Weight:0.4 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Input Signal Range:40-20 mA
-
Number of Input Points:8
-
Operating Temperature:0°C to 60°C
-
Relative Humidity:5% to 95% (non-condensing)
-
Power Consumption:Typically less than 10mA at 24VDC
-
Enclosure Rating:IP20
-
Power Consumption:Less than 2W
-
Connectivity:Industry-standard connectors
Information
Overview
Manuals
Need More Info
- IC600BF843 Analog Input Module
- Provides multiple analog input channels for voltage or current signals
- Supports high-accuracy measurement for precise process monitoring.
The The GE Fanuc Emerson IC600BF843 functions as an analog input module in the Series Six lineup. Capable of processing eight distinct inputs, this module accommodates a variety of input ranges, including 0 to 10 volts, -10 to 10 volts, and 4 to 20 mA (defined in a 1 to 5 volt range). The resolution of this unit is quantified at 12 binary bits, facilitating detailed data readings.
For precise performance, the module offers impressive accuracy ratings. Typical voltage input accuracy is measured at 0.025% of full scale when operating at 25 degrees Celsius, while maximum voltage input accuracy reaches 0.050% under the same temperature conditions. For current inputs, typical accuracy is rated at 0.075%, and the maximum accuracy stands at 0.125%, again measured at 25 degrees Celsius.
The device also includes LED indicators for easy status monitoring, providing visual feedback for operational conditions. It is engineered for reliable functionality within an operating temperature of 0 to 60 degrees Celsius at the outside of the rack. Overall, the IC600BF843 serves as a dependable component for tasks requiring accurate analog input processing in various industrial environments.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
GE IC660BBR100 RELAY OUTPUT MODULE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
We know that questions arise, and that sometimes you need more details or a closer look to make the right decision. That’s why we make it easy for you to reach out directly—so you’re never left wondering.
With our team, you’re just a message away from clarity and confidence. Whether you have a specific question, need a particular image, or want more details, the request form puts you in control. Let us know what you need, and we’ll bring the answers straight to you—no guesswork required!
FAQ View All FAQ
-
What is IC600BF843?IC600BF843 is an Analog Input Module
-
What are the basic specifications of the IC600BF843 Analog Input Module?It is a multi-channel analog input module designed to read voltage or current signals from field sensors in industrial control systems.
-
What types of signals does the IC600BF843 support?It supports standard analog signals such as 0–10 V, 4–20 mA, and other compatible process signals.
-
What is the input range for the IC600BF843 module?The module can accept input voltages from 0–10 V and input currents from 4–20 mA, depending on configuration.
-
Is the IC600BF843 suitable for industrial environments?Yes, it is built for reliable operation in harsh industrial conditions with resistance to electrical noise and temperature variations.
-
How is the IC600BF843 installed in a control system?It is mounted in a compatible rack or backplane and connected to field sensors via terminal blocks.
