PR6423/002-121 CON041

Eddy-current proximity measurement set
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

Emerson PR6423/002-121 CON041 combines a PR6423 eddy-current probe execution with a CON041 signal converter reference for rotating-machinery displacement measurement.
  • Manufacturer part number
    PR6423/002-121 CON041
  • Shipping
    Swift global dispatch
  • Condition
    New, original product
  • Shipping size (est.)
    16cm × 15cm × 2cm
  • Country of Origin
    USA
Get a quick price for PR6423/002-121 CON041
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 0

    Review your reference

    Send the full PR6423/002-121 CON041 marking, quantity and label photos. We review the item and any version details that need clarification.

  • 1

    Confirm the offer

    Check the quoted PR6423/002-121 CON041 reference, condition, included items and expected dispatch date before approving your order.

  • 2

    Arrange dispatch

    Confirm delivery details for your PR6423/002-121 CON041 order and receive the tracking number when it becomes available.

  • Match the complete marking

    Include PR6423/002-121 CON041 and any revision or assembly number visible on the item. Keep the exact reference on your enquiry and quotation.

  • Check the offered item before ordering

    Request available label and connection photos. Have your maintenance team compare the offered PR6423/002-121 CON041 with the installed equipment and applicable manufacturer documentation.

Technical specifications for PR6423/002-121 CON041

  • Manufacturer:
    Emerson
  • Product Category:
    Machinery Monitoring Systems
  • Spare Part Number:
    PR6423/002-121 CON041
  • Weight:
    0.15 kg
  • Tariff Code:
    8537101190
  • Sensor family:
    PR6423, 8 mm eddy-current probe
  • Converter family:
    CON041
  • Measurement principle:
    Noncontact eddy-current displacement
  • Sensor execution:
    PR6423/002-121
  • Converter identity:
    CON041; match actual label
  • System boundary:
    Probe, converter, cable and target form the measurement chain
  • PR6423 linear range:
    2 mm
  • PR6423 initial gap:
    0.5 mm
  • PR6423 scale factor:
    8 V/mm ±5% at 0 to 45 °C
  • PR6423 target diameter:
    25 mm minimum
  • PR6423 target material:
    42CrMo4 (AISI/SAE 4140) reference
  • PR6423 ingress protection:
    IP66
  • PR6423 sensor tip:
    PEEK

Information

Overview Downloads Applications / Compatibility Product Precautions
  • The selected probe and converter measure relative shaft displacement after the complete chain is matched and calibrated.
Target surface: Conductive shaft track at the probe location
Signal handoff: Check conditioned converter output at the intended monitor input
Service record: Retain the initial gap and pre-service signal baseline
The PR6423/002-121 CON041 measurement set senses relative movement between a conducting shaft target and the noncontact PR6423 probe tip. The converter conditions the probe signal for a compatible monitoring input. Selection of the target, cable and converter determines the calibrated measurement chain.

The PR6423 family uses an 8 mm probe tip and is applied to shaft vibration, axial position and related relative displacement measurements. CON041 is a matching eddy-current signal-converter family. The exact /002-121 probe option and converter execution must be checked against the supplied labels before assigning family ratings to the offered combination.

During replacement, retain the mechanical target track, mounting position and cable route. Set the initial probe gap using the approved converter output and compare the restored signal with the pre-service baseline before enabling machinery protection.
Measurement system reference: PR6423 / CON041 measurement chain. Match the installed configuration and interfaces.
Technical downloads for Emerson PR6423/002-121 CON041: an Apter Power technical reference and installation verification guide.
Both documents support product review and site preparation. Follow the approved project drawings, equipment procedures and local safety controls during installation.
Installation and commissioning checks for Emerson PR6423/002-121 CON041.
Match the probe option

Compare PR6423/002-121 and CON041 with both offered labels and the installed channel.

Inspect the target

Review target material, surface condition and probe track.

Preserve the cable chain

Match extension cable, connector and total cable arrangement.

Protect the probe

Avoid impact on the tip and over-bending the cable at its casing exit.

Set the cold gap

Use the approved converter voltage and site gap-setting procedure.

Verify the channel

Compare the steady gap and dynamic response against the baseline.

Alternative Names

PR6423/002-121 / CON041

Technical notes

Technical basis: Emerson PR 642x eddy-current sensor specifications and CON041 signal-converter product information.

Applicability: PR6423 and CON041 family descriptions establish the measurement roles; option-specific ratings for /002-121 are reserved for the supplied labels and approved chain configuration.

Commissioning evidence: Compare pre-service and post-service I/O or controller diagnostics, record the affected points, and retain the signed site acceptance result for PR6423/002-121 CON041.

FAQ View All FAQ

  • Why is converter matching important for PR6423/002-121 CON041?
    The PR6423 probe, cable and CON041 converter form a calibrated chain; changing one component can alter sensitivity or baseline.
  • What can cause a baseline shift after fitting PR6423/002-121 CON041?
    Check probe gap, target track, cable continuity and converter setting before changing alarm limits.
  • How should shaft target condition be assessed for PR6423/002-121 CON041?
    Inspect material, surface finish, deposits and runout at the measurement track.
  • Can PR6423/002-121 CON041 be used as a stand-alone vibration transmitter?
    The complete measurement requires the matched converter and appropriate monitoring input.
  • What should be recorded before removing PR6423/002-121 CON041?
    Record probe insertion depth, target position, total cable path, converter identity and monitored gap voltage.
  • How can an intermittent signal from PR6423/002-121 CON041 be isolated?
    Inspect connector seating, cable damage, converter power and target movement under controlled conditions.
  • How should the initial gap be set for PR6423/002-121 CON041?
    Use the applicable converter output and machine procedure rather than a visual gap estimate.
  • What acceptance test should follow installation of PR6423/002-121 CON041?
    Compare stable gap output and dynamic channel behavior with an approved machine condition before returning protection to service.
