Technical specifications for 5X00594G01
-
Manufacturer:Emerson
-
Product Category:DCS Systems
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Product class:Thermocouple input module
-
Platform:Ovation I/O
-
Channel count:16
-
Input families:±20 mV; ±50 mV; ±100 mV
-
Field-interface pairing:1C31116G05
-
Signal class:Low-level thermocouple / millivolt
-
Main power:2.4 W
-
Full model:5X00594G01
Information
Overview
Manuals
Common Applications
Product Precautions
WESTINGHOUSE 5X00594G01 expands low-level temperature acquisition to sixteen channels. Correct thermocouple type, polarity, cold-junction arrangement, cable material and the 1C31116G05 pairing must be verified as one system.
- Sixteen thermocouple channels
- Low-level millivolt acquisition
- ±20, ±50 and ±100 mV families
- 1C31116G05 interface pairing
The installed signal path is Thermocouple sensor → 1C31116G05 field interface → 5X00594G01 conversion stage → Ovation controller. Record the as-left channel assignment and verify the affected path before release.
Important Notice: Isolate affected thermocouple circuits before handling WESTINGHOUSE 5X00594G01.
WESTINGHOUSE 5X00594G01 Manuals & Downloads
WESTINGHOUSE 5X00594G01 Technical Reference (PDF)WESTINGHOUSE 5X00594G01 Installation & Commissioning Guide (PDF)
The Technical Reference presents the applicable model data and interface details; the Installation & Commissioning Guide organizes field preparation, controlled replacement and acceptance checks for WESTINGHOUSE 5X00594G01.
Multipoint temperature monitoring
Collects sixteen temperature channels in an Ovation cabinet.
Low-level millivolt acquisition
Accepts the documented ±20, ±50 and ±100 mV range families.
Legacy input replacement
Restores an existing 5X00594G01 temperature-input position.
Channel fault isolation
Separates sensor, extension wire, terminal, field interface and conversion checks.
Apply these controls to WESTINGHOUSE 5X00594G01 before isolation, removal, reconnection, energization and release.
1
Isolate affected thermocouple circuits before handling WESTINGHOUSE 5X00594G01.
2
Confirm the G01 identity and the installed 1C31116G05 field-interface module.
3
Record sensor type, polarity, range, engineering units and cold-junction arrangement for all channels.
4
Use matching thermocouple extension wire and preserve the original polarity end to end.
5
Keep low-level wiring segregated from power and switching conductors.
6
Do not inject voltage outside the configured millivolt family.
7
Commission with a traceable thermocouple or millivolt source at representative points.
8
Release the module only after every used channel and its configured alarm behavior agree with the site test.
Technical notes
WESTINGHOUSE 5X00594G01 is an Ovation sixteen-channel thermocouple input module for low-level millivolt temperature signals.
FAQ View All FAQ
-
How many thermocouple channels belong to WESTINGHOUSE 5X00594G01?It provides sixteen thermocouple input channels.
-
Which low-level ranges are associated with WESTINGHOUSE 5X00594G01?The documented input families are ±20 mV, ±50 mV and ±100 mV.
-
Which field-interface module pairs with WESTINGHOUSE 5X00594G01?The documented pairing is 1C31116G05.
-
What type of wiring is critical for WESTINGHOUSE 5X00594G01?Use the correct thermocouple extension-wire material and preserve polarity and shield routing.
-
What main-power value is documented for WESTINGHOUSE 5X00594G01?The planning data lists 2.4 W main power.
-
Why must channel range be checked on WESTINGHOUSE 5X00594G01?The configured millivolt family must match the installed sensor and project database.
-
How should WESTINGHOUSE 5X00594G01 be calibrated in the field?Apply a traceable thermocouple or millivolt source and compare terminal input with the controller value.
-
When is WESTINGHOUSE 5X00594G01 ready to return to service?Verify sensor type, polarity, range, cold-junction arrangement, channel accuracy and alarm action.
