Technical specifications for 5X00300G01
-
Manufacturer:Emerson
-
Product Category:DCS Systems
-
Spare Part Number:5X00300G01
-
Estimated shipping dimensions:12.1x5.2x16.6cm
-
Weight:0.3 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Interface:Profibus DP
-
Channels:2
-
Personality module:5X00321G01
-
System role:Bus interface between Ovation and Profibus devices
-
Main power:5.1 W/VA typical in the documented configuration
Information
Overview
Manuals
Common Applications
Product Precautions
Westinghouse 5X00300G01 is the Ovation electronics module for a two-channel Profibus DP interface used to exchange data with decentralized fieldbus devices.
- Provides two network channels for the documented profibus dp interface module function.
- Handles digital Profibus DP communication through the specified Ovation I/O subsystem.
- Works with 5X00321G01 Profibus interface personality module.
- The module provides the electronics side of the documented Ovation Profibus module combination.
The profibus dp interface module belongs in the controlled Ovation I/O subsystem and works with 5X00321G01 Profibus interface personality module. Its field connection, companion hardware and project configuration must be reviewed together before the channel is returned to service.
Important Notice: Use 5X00300G01 only with 5X00321G01 Profibus interface personality module; verify the field interface and controlled configuration before energizing the subsystem.
Westinghouse 5X00300G01 Manuals & Downloads
Westinghouse 5X00300G01 Technical Reference (PDF)Westinghouse 5X00300G01 Installation & Commissioning Guide (PDF)
The first document covers the product function, system role and technical selection. The installation guide covers identification, connection checks, commissioning and the acceptance record.
Installed-base maintenance
Restores the documented profibus dp interface module position without changing the approved system architecture.
Loop or channel service
Supports verification of digital Profibus DP communication at the assigned control-system channel.
Planned replacement
Provides an exact-identity replacement path when 5X00321G01 Profibus interface personality module and the field interface have been confirmed.
Commissioning support
Allows the responsible engineer to prove wiring, configuration, status and response for two network channels.
Before installing Westinghouse 5X00300G01, confirm the documented system, interfaces and controlled configuration.
1
Match the complete 5X00300G01 marking to the work order and installed position before removal.
2
Confirm 5X00321G01 Profibus interface personality module before making or breaking any field connection.
3
Keep the assigned digital Profibus DP communication within the documented subsystem and range.
4
Record terminal designations, polarity, common and shield treatment before disconnecting conductors.
5
Inspect module seating, connector keying, terminal condition and strain relief before power is restored.
6
Restore the controlled channel configuration, range selection and alarm or timeout behavior after installation.
7
Check local indicators and controller diagnostics for internal, communication or channel faults during commissioning.
8
Prove the intended response across two network channels and record the acceptance result before release.
Technical notes
Use 5X00300G01 only with 5X00321G01 Profibus interface personality module; verify the field interface and controlled configuration before energizing the subsystem.
FAQ View All FAQ
-
What industrial network is interfaced by Westinghouse 5X00300G01?The module connects Ovation to Profibus DP devices.
-
How many Profibus paths are provided by Westinghouse 5X00300G01?Two network channels are available in the documented interface.
-
Which personality module completes Westinghouse 5X00300G01?The required Profibus field-interface partner is 5X00321G01.
-
What system task is assigned to Westinghouse 5X00300G01?It exchanges digital process and status data between the Ovation system and decentralized Profibus devices.
-
What typical main-power value is documented for Westinghouse 5X00300G01?The listed main-power requirement is 5.1 W/VA typical for the documented configuration.
-
Why must both network channels of Westinghouse 5X00300G01 be commissioned separately?Each channel represents its own Profibus path, so addressing, device communication and channel status must be proven for both interfaces.
-
What hardware identity should be checked before installing Westinghouse 5X00300G01?Verify the 5X00300G01 electronics module is paired with 5X00321G01 rather than with a personality module from another specialty-I/O interface.
-
Which results demonstrate that Westinghouse 5X00300G01 is communicating correctly?Both Profibus channels should recognize their configured devices, exchange the expected data and remain free of bus-interface faults under normal load.
