      Bently Nevada 84661-6
      Bently Nevada 84661-6
      Bently Nevada 84661-6
      Bently Nevada 84661-6
      Bently Nevada 84661-6
      Bently Nevada 84661-6
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      84661-6

      Armored Sensor Cable
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 84661-6 is a six-foot armored, twisted and shielded two-conductor cable for a compatible accelerometer installation. It has a two-socket moisture-resistant female connector at one end and terminal lugs at the other.

      Ask our team:

      Get a quick price for： 84661-6
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 84661-6

      Technical specifications for 84661-6

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        84661-6
      • Estimated shipping dimensions:
        27x25x2cm
      • Weight:
        0.16 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Cable length:
        6 ft
      • Conductor configuration:
        Two-conductor twisted pair
      • Conductor size:
        22 AWG
      • Shielding:
        Shielded
      • Armor:
        Armored cable
      • Sensor-end connector:
        Two-socket moisture-resistant female
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 84661-6 is a six-foot armored, twisted and shielded 22 AWG cable for a compatible accelerometer connection.
      • Two-conductor twisted, shielded 22 AWG cable
      • Armored execution for the 84661 ordering series
      • Moisture-resistant two-socket female sensor connector
      • Terminal-lug termination at the receiving end

      The -6 order suffix selects the six-foot cable execution. Confirm the installed accelerometer, cable route and receiving-circuit assignments before replacement.

      Important Notice: Verify the complete 84661-6 marking and the documented six-foot routing before making either connection.

      Bently Nevada 84661-6 Manuals & Downloads
      Bently Nevada 84661-6 Technical Reference (PDF)Bently Nevada 84661-6 Installation & Commissioning Guide (PDF)

      The technical reference records the verified 84661 cable construction and interface; the separate guide sets out pre-installation, wiring and functional acceptance checks.

      Accelerometer connectionBently Nevada 84661-6: Connect the documented compatible sensor to its assigned receiving circuit through the armored cable.
      Protected cable routeUse the armored construction where the approved machinery-monitoring installation calls for it.
      Shielded signal pathRetain the documented shield and grounding practice for the sensor-signal pair.
      Maintenance replacementRestore a matching six-foot cable run without changing the recorded connector or terminal assignments.
      Read the applicable accelerometer and monitoring-system instructions before work. Confirm Bently Nevada 84661-6, both cable interfaces and the approved maintenance state.
      1
      Confirm the exact 84661-6 cable marking and six-foot routing record.
      2
      Place the affected machine and monitor channel in the approved maintenance state.
      3
      Record the as-found sensor connector, cable path and terminal-lug positions.
      4
      Inspect the two-socket female connector and mating sensor interface.
      5
      Check the armored shielded cable body for damage or trapped sections.
      6
      Match both 22 AWG conductors and terminal lugs to the approved circuit drawing.
      7
      Restore the documented shielding and grounding arrangement without guessing new bonds.
      8
      Verify channel diagnostics and controlled signal response before release.

      Technical notes

      Technical notes

      Use only with the documented accelerometer and receiving circuit. Confirm the complete 84661-6 identity, connector mating, six-foot routing and terminal-lug assignments before installation; avoid unverified voltage, current and temperature ratings.

      FAQS

      • What cable is identified by 84661-6?
        84661-6 is a six-foot armored cable in the Bently Nevada 84661 series for a matched accelerometer connection.
      • How long is the 84661-6 cable?
        The suffix -6 specifies a 6 ft cable length.
      • Which connector does 84661-6 use at the sensor end?
        It has a two-socket moisture-resistant female connector at one end and terminal lugs at the other.
      • Is 84661-6 armored or unarmored?
        84661-6 is the armored 84661-series option; the similarly described 9571-NN cable is unarmored.
      • What conductor size is specified for 84661-6?
        The cable uses a twisted, shielded pair of 22 AWG conductors.
      • What termination is opposite the connector on 84661-6?
        The end opposite the female connector is finished with terminal lugs.
