      3500/25 149369-01

      Enhanced Keyphasor Module
      In Stock
      Bently Nevada 3500/25 149369-01
      Bently Nevada 3500/25 149369-01
      Bently Nevada 3500/25 149369-01
      Bently Nevada 3500/25 149369-01
      Bently Nevada 3500/25 149369-01
      Bently Nevada 3500/25 149369-01
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      Enhanced Keyphasor Module
      TWO HALF-HEIGHT 2-CHANNEL
      KEYPHASOR CARDS
      ISOLATED I/O MODULE WITH
      INTERNAL TERMINATIONS

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 3500/25 149369-01
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 3500/25 149369-01

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        149369-01
      • Estimated shipping dimensions:
        2.5x25.7x12cm
      • Weight:
        0.34 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Accuracy:
        +/- 0.2% FS
      • Input Range:
        4-20 mA or 0-5 V
      • Power Supply:
        12V DC
      • Communication Protocol:
        RS485
      • Operating Temperature:
        -40°F to 185°F (-40°C to 85°C)
      • Humidity:
        95%, non-condensing
      • Storage Temperature:
        -40°C to +85°C (-40°F to +185°F)
      Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      The 3500/25 149369-01 is an enhanced keyphase module manufactured by Bentley Nevada, a subsidiary of General Electric (GE). It is a core component of the 3500 monitoring system, a half-height dual-channel module specifically designed for condition monitoring of large rotating machinery.
        • System-wide Signal Sharing
        • Enhanced Signal Processing
        • High Flexibility and Scalability
      The 3500/25 Enhanced Keyphasor Module is a half-height, two-channel module used to provide Keyphasor signals to the monitor modules in a 3500 rack. The module receives input signals from proximity probes or magnetic pickups and converts the signals to digital Keyphasor signals that indicate when the Keyphasor mark on the shaft coincides with the Keyphasor transducer. The 3500 Machinery Protection System can accept up to four Keyphasor signals for normal configuration and up to eight Keyphasor signals in a paired configuration. The Enhanced Keyphasor Module is an improved 3500 system module. It offers expanded Keyphasor signal processing capabilities over the previous design while maintaining complete downward-compatibility in terms of form, fit and function with existing Keyphasor modules for use in legacy systems. The Keyphasor module, PWA 125792-01, is completely replaced by the updated 149369-01 module.

      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
       Bently Nevada 3500/25 149369-01 Enhanced Keyphasor Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Nuclear Power
      Providing high-precision speed references for main feedwater pumps to ensure cooling system stability.

      Steel & Metallurgy
      Used for blast furnace blowers to analyze dynamic balance through Keyphasor signals.

      Pulp & Paper
      Monitoring dryer section drive systems to analyze the synchronization of multi-support shafting.

      Air Separation
      Monitoring air compressors to judge rotor thermal bow through 1X vector analysis.

      Cement Production
      Vibration analysis for large exhaust fans to reduce downtime caused by uneven dust accumulation.

      Marine Propulsion
      Monitoring main propulsion turbines to provide propeller shaft speed and phase data.

       Ensure the module is perfectly matched with its corresponding I/O module (isolated or non-isolated) and that sensor types and trigger thresholds are correctly configured in the software to prevent signal false-triggering or loss. During installation or replacement, verify slot alignment to avoid damaging backplane pins by forcing the card. Additionally, regularly verify the logical distribution of Keyphasor signals to ensure all monitor modules in the rack receive synchronized and accurate speed and phase references.
