      Bently Nevada 3500/22M 288055-01
      Bently Nevada 3500/22M 288055-01
      Bently Nevada 3500/22M 288055-01
      Bently Nevada 3500/22M 288055-01
      Bently Nevada 3500/22M 288055-01
      Bently Nevada 3500/22M 288055-01
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      3500/22M 288055-01

      DATA INTERFACE MODULE
      In Stock

      Product Describe：

      3500/22M 288055-01
      DATA INTERFACE MODULE
      TRANSIENT
      USB-B CONNECTOR
      FOR 3500 MONITORING SYSTEM
      <1 mAdc, Dry Contact to Common

      Ask our team:

      Get a quick price for： 3500/22M 288055-01
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information FAQ More Details

      Technical specifications for 3500/22M 288055-01

      Technical specifications for 3500/22M 288055-01

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        288055-01
      • Estimated shipping dimensions:
        2.5x25x24cm
      • Weight:
        0.82 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Current Rating:
        5 AMP
      • Power Supply:
        24VDC/120 VAC
      • KBAUD RATE:
        115.2 KBAUD RATE
      • Power Consumption:
        10.5 Watts
      • Battery Life:
        38 years @ 50°C
      Ask for Quote

      Information

      Information

      Overview Manuals Core functions of the product
      The Bently Nevada 3500/22M (Part No. 288055-01) is a Standard Transient Data Interface (TDI) module, acting as the primary communicator between the 3500 monitoring system and System 1 software.
        • Interface Between the 3500 Monitoring System and System 1 Machinery Management Ssoftware
        • Combines Capability of 3500/20 RIM with Communication Processor
        • Operates in Conjunction with the M Series Monitors
      The Bently Nevada™ 3500/22M Transient Data Interface (TDI)is the interface between the 3500 monitoring system andcompatible software (System 1 Condition Monitoring andDiagnostic software and 3500 System Configurationsoftware). The TDI combines the function of a 3500/20 RackInterface Module (RIM) with the data collection capability of acommunication processor such as TDXnet
      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Bently Nevada 3500/22M 288055-01 DATA INTERFACE MODULE Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Data Collection and Integration: Combining the functionality of the old 3500/20 Rack Interface Module (RIM) with the data collection capabilities of communication processors such as TDXnet. Transient and static data: It can continuously collect steady-state and transient dynamic waveform data of machinery, and transmit it to the host through Ethernet for fault diagnosis. Configuration management: The panel is equipped with a key lock, which can place the rack in "RUN" or "GRAM" mode for locking or allowing remote reconfiguration.

      FAQS

      • 3500/22M 288055-01 What is it?
        3500/22M 288055-01 is DATA INTERFACE MODULE
      • Do you offer global delivery services?
        Yes. We ship globally, and we are able to quickly deliver parts globally to any corner of the world. Unless otherwise specified, we will ship your order via (DHL). We can also ship through FedEx, UPS, and TNT. We can also use your account.
      • How many parts do you have in stock?
        We have an extensive stock base consisting of ten thousands of new and discontinued automation parts including those from leading manufacturers such as:Control Systems (DCS, PLC, CNC) ,Panel Controllers,HMI and Display Panels,Drives,Encoders and Resolvers,Power Supplies. If you are unable to find what you are looking for then don’t panic.
      • Where is 3500/22M located in the rack ?
        Ina 3500 rack, the TDI is located in the slot next to the power spplies
      • What is the difference between 288055-01 and the older 138607-01?
        288055-01 is the new version of the USB interface; 138607-01 is the old version of the optical fiber interface.
      • What is the function of the component 3500/22M ?
        The component link 3500 monitoring system and compatible sftware.
