      330730-040-00-00

      3300 XL 11 mm standard extension cable
      In Stock
      Ships by Sunday, November 8
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      Bently Nevada 330730-040-00-00 is 3300 xl 11 mm standard extension cable. It completes a five-metre 3300 XL 11 mm transducer loop when combined with the matched one-metre probe and Proximitor Sensor.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330730-040-00-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330730-040-00-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330730-040-00-00
      • Estimated shipping dimensions:
        20.5x22.4x3.3cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Cable length:
        4.0 m (13.1 ft)
      • Cable construction:
        Standard cable
      • Agency approval option:
        00
      • Cable impedance:
        75 ohm triaxial
      • Cable insulation:
        FEP
      • Core resistance:
        1.0 +/- 0.25 ohm
      • Jacket resistance:
        0.3 +/- 0.1 ohm
      • Capacitance:
        69.9 pF/m typical
      • Minimum bend radius:
        25.4 mm (1.0 in)
      • Maximum connector torque:
        0.565 N m (5 in lbf)
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330730-040-00-00 is 3300 xl 11 mm standard extension cable. It completes a five-metre 3300 XL 11 mm transducer loop when combined with the matched one-metre probe and Proximitor Sensor.
      • Provides four metres of system cable length
      • Uses standard FEP-insulated triaxial construction
      • Carries the eddy-current probe signal through ClickLoc connectors
      • Preserves the calibrated 11 mm system-length relationship

      330730-040-00-00 is installed with 3300 XL 11 mm probe, five-metre 3300 XL 11 mm Proximitor Sensor, ClickLoc connector pair, compatible Bently Nevada monitor channel.

      Engineered applications include Radial shaft-vibration loops, Axial position monitoring, Differential-expansion measurement, Steam-turbine proximity-system renewal.

      Important Notice: Confirm that probe length plus 330730-040-00-00 equals the Proximitor Sensor system length, keep both ClickLoc interfaces clean and finger-tight, and support the cable above the minimum bend radius before loop verification.

      Apter Power 330730-040-00-00 Manuals and Guides

      Apter Power 330730-040-00-00 Product Technical Reference PDF330730-040-00-00 Engineering Installation and Verification Workbook

      The first document presents model-specific technical identity and engineering data. The second provides a separate installation, connection and commissioning workflow.

      Radial shaft-vibration loops

      330730-040-00-00 supports this documented 3300 XL 11 mm Proximity Transducer System engineering task.

      Axial position monitoring

      330730-040-00-00 supports this documented 3300 XL 11 mm Proximity Transducer System engineering task.

      Differential-expansion measurement

      330730-040-00-00 supports this documented 3300 XL 11 mm Proximity Transducer System engineering task.

      Steam-turbine proximity-system renewal

      330730-040-00-00 supports this documented 3300 XL 11 mm Proximity Transducer System engineering task.

      Read the applicable Bently Nevada instructions before work. Verify 330730-040-00-00 and the installed-system configuration.
      1

      Verify the complete 330730-040-00-00 marking and its documented 3300 XL 11 mm Proximity Transducer System position before field work.

      2

      Place the monitored machine and associated protection channel in the approved maintenance state before disconnecting 3300 XL 11 mm standard extension cable.

      3

      Protect every exposed connector and cable end from oil, moisture, dirt and impact while 330730-040-00-00 is open.

      4

      Record probe, extension-cable and Proximitor Sensor identities so the calibrated system length is preserved.

      5

      Route 330730-040-00-00 without sharp bends, crushing, abrasion or tensile loading at either coaxial termination.

      6

      Clean and finger-tighten each ClickLoc connection; never transfer connector torque or wiring practice from a different transducer family.

      7

      Set the static gap only after mechanical mounting and the complete matched loop have been confirmed.

      8

      Verify polarity, dynamic response and alarm action before returning the machinery-protection channel to service.

      Technical notes

      Confirm that probe length plus 330730-040-00-00 equals the Proximitor Sensor system length, keep both ClickLoc interfaces clean and finger-tight, and support the cable above the minimum bend radius before loop verification.

      FAQ View All FAQ

      • Which Bently Nevada transducer system uses 330730-040-00-00?
        330730-040-00-00 belongs to the 3300 XL 11 mm Proximity Transducer System and must be combined only with the probe, extension cable and Proximitor Sensor arrangement documented for that system.
      • How should engineers confirm the system length for 330730-040-00-00?
        Add the installed probe lead and extension-cable lengths, then compare the total with the matching Proximitor Sensor length before energizing the channel.
      • What connector checks are required for 330730-040-00-00?
        Inspect both mating surfaces for contamination or damage, align the ClickLoc connector correctly and tighten it finger-tight until the locking action is complete.
      • How should 330730-040-00-00 be routed in a machinery enclosure?
        Maintain the documented bend radius, provide mechanical support and keep the cable away from sharp edges, hot surfaces and locations that can impose tensile load.
      • What must be recorded before replacing 330730-040-00-00?
        Record the full catalog marking, mounting position, companion component numbers, cable route, monitor channel, static gap and as-found polarity.
      • How is the channel recommissioned after installing 330730-040-00-00?
        Restore the matched loop, verify supply and bias voltage, prove movement through the expected linear region and test the configured alarm or trip response under controlled conditions.
      • Can 330730-040-00-00 be mixed with another probe family?
        Use only combinations explicitly permitted by the 3300 XL 11 mm Proximity Transducer System documentation; connector fit alone does not establish electrical calibration or interchangeability.
      • What maintenance condition should trigger inspection of 330730-040-00-00?
        Inspect the assembly after cable impact, connector contamination, abnormal bias voltage, unstable vibration, loss of linear response or any work that changes the probe mounting.
