The 330707-00-20-10-11-00 has a 3.94 V/mm (100 mV/mil) output for non-contacting vibration and displacement measurements on fluid film bearing machines. The large 11 mm tip enables this transducer system to have a longer linear range compared to our standard 3300 XL 8 mm Transducer System.
Extended linear range
High interchangeability
Superior RFI/EMI immunity
The 3300 XL 11 mm Proximitor Sensor is designed to replace the 7200-series 11 mm and 14 mm Transducer Systems. When upgrading from the 7200-series system to the 3300 XL 11 mm system, every component must be replaced with 3300 XL 11 mm components. In addition, the monitoring system must be updated. If using a 3500 Monitoring System, an updated version of the configuration software that lists the 3300 XL 11 mm Transducer System as a compatible option is required.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330707-00-20-10-11-00 3300 XL 11 mm Proximity Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas
Monitors vibration and position in pumps, compressors, and turbines used in upstream, midstream, and downstream operations.Ensures reliable performance in harsh oilfield and process environments.
Power Generation
Used for shaft vibration and thrust position measurement in steam turbines, gas turbines, and generators. Protects critical rotating equipment in utility and industrial power plants.
Aerospace
Provides precision measurement for aircraft engines and ground test turbine equipment. Supports condition monitoring in high‑speed aerospace rotating systems.
Petrochemical
Applied in reformers, crackers, and large process compressors in refinery and chemical plants. Delivers stable signals in corrosive and high‑temperature process areas.
Mining & Metals
Monitors fans, blowers, and large motors in mineral processing and metal production facilities. Maintains accuracy in heavy industrial and high‑vibration sites.
Marine
Used in shipboard propulsion turbines, compressors, and marine power systems. Ensures stable measurement under harsh marine environmental conditions.
The 3300 XL 11 mm Proximitor Sensor has the same advanced features found in the 3300 XL 8 mm Proximitor Sensor. Its thin design allows it to be mounted in either a high-density DIN-rail installation or a more traditional panel mount configuration. Improved RFI/EMI immunity allows the 3300 XL Proximitor Sensor to achieve European CE mark approvals without any special mounting considerations. This RFI immunity also prevents the transducer system from being adversely affected by nearby high frequency radio signals. SpringLoc terminal strips on the Proximitor Sensor require no special installation tools and facilitate faster, highly robust field wiring connections.
It is a 3300 XL 11 mm diameter proximity probe with 5/8-18 UNF mounting thread and 20 ft integral cable.
What is the nominal sensitivity of 330707-00-20-10-11-00?
Nominal sensitivity is 100 mV/mil (3.94 V/mm) ±10% over the linear range, including system interchangeability error.
What linear range does 330707-00-20-10-11-00 provide?
The standard linear measurement range for this 11 mm probe is 2.0 mm (80 mils) from the probe tip to the target surface.
What target material is 330707-00-20-10-11-00 calibrated for?
It is factory-calibrated for AISI 4140 steel target; calibration for other ferrous target materials is available on request.
What applications is 330707-00-20-10-11-00 designed for?
It is intended for radial vibration, axial position, and speed measurement on rotating machinery such as turbines and compressors.
