      Bently Nevada 330500-02-CN
      Bently Nevada 330500-02-CN
      Bently Nevada 330500-02-CN
      Bently Nevada 330500-02-CN
      Bently Nevada 330500-02-CN
      Bently Nevada 330500-02-CN
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330500-02-CN

      330500 Velomitor Piezo-velocity Sensor
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330500-02-CN is a 330500 Velomitor piezo-velocity sensor with an M8 x 1 mounting adapter. It measures absolute vibration of bearing housings, casings and structural surfaces for a compatible monitor channel.

      Ask our team:

      Get a quick price for： 330500-02-CN
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330500-02-CN

      Technical specifications for 330500-02-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330500-02-CN
      • Estimated shipping dimensions:
        7.8x2.5x2.5cm
      • Weight:
        0.14 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Mounting-adapter code:
        02
      • Mounting adapter:
        M8 x 1
      • Sensitivity:
        3.94 mV/mm/s (100 mV/in/s), +/-5%
      • Frequency response:
        4.5 Hz to 5 kHz, +/-3 dB
      • Precision frequency response:
        6 Hz to 2.5 kHz, +/-0.9 dB
      • Velocity range:
        1270 mm/s (50 in/s) peak
      • Amplitude linearity:
        +/-2% to 152 mm/s peak
      • Mounted resonance:
        Greater than 12 kHz
      • Output bias:
        -12 +/-3 V
      • Dynamic output impedance:
        Less than 2400 ohm
      • Noise floor:
        0.004 mm/s RMS nominal
      • Case isolation:
        Isolated
      • Operating temperature:
        -55 to +121 degC
      • Maximum shock:
        5000 g peak
      • Housing material:
        316L stainless steel
      • Connector:
        2-pin MIL-C-5015
      • Mounting torque:
        32 to 46 kg-cm (24 to 40 in-lb)
      • Recommended cable length:
        Up to 63 m under stated datasheet conditions
      • Signal polarity:
        Motion toward connector: Pin A positive relative to Pin B
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      330500 Velomitor Piezo-velocity Sensor provides the documented interface for its installed Bently Nevada 330500 Velomitor Piezo-velocity Sensor system.
      • Measures absolute vibration on a mounted machine surface
      • Uses integrated solid-state electronics for velocity output
      • Provides an isolated stainless-steel sensor case
      • Connects through a two-pin MIL-C-5015 interface

      330500-02-CN converts absolute casing or bearing-housing vibration into a velocity-proportional electrical signal for machinery-condition monitoring. The installation uses the manufacturer-specified host position, companion hardware and field/control wiring for the intended industrial application.

      System commissioning includes identity checks, connection verification, controlled energization and functional diagnostics for 330500-02-CN.

      Important Notice: Confirm the complete 330500-02-CN marking, approved system arrangement, connection records and controlled functional test before commissioning or replacement.

      Apter Power 330500-02-CN Manuals and Guides
      Apter Power 330500-02-CN Product Technical Reference PDF330500-02-CN Engineering Installation and Verification Workbook
      The first document organizes model-specific technical identity and engineering data. The second provides a separate field workflow for installation, connection checks and commissioning records.
      Bearing-housing vibration monitoringM8 x 1 mounting point supports the engineered 330500-02-CN arrangement.
      Machine-casing vibration measurementTwo-pin MIL-C-5015 mating cable supports the engineered 330500-02-CN arrangement.
      Structural vibration observationCompatible Bently Nevada monitor channel supports the engineered 330500-02-CN arrangement.
      Velocity-sensor replacement and verificationPrepared flat machine surface supports the engineered 330500-02-CN arrangement.
      Read the applicable Bently Nevada installation instructions before work. Verify 330500-02-CN and the installed-system configuration.
      1Verify the full 330500-02-CN marking and M8 x 1 adapter before disturbing the installed sensor.
      2Place the monitored machine and vibration channel in the approved maintenance state.
      3Clean the mounting surface and adapter threads without damaging the sensor base.
      4Apply the documented mounting torque and do not use the connector body as a tightening point.
      5Preserve Pin A and Pin B polarity when reconnecting the two-pin MIL-C-5015 cable.
      6Route and clamp the sensor cable so it cannot transmit movement or impact into the housing.
      7Confirm output bias and monitor-channel scaling before dynamic testing.
      8Prove velocity response and alarm action before returning the machine to service.

      Technical notes

      Technical notes

      Mount 330500-02-CN on a clean prepared surface using the M8 x 1 adapter and documented torque. Preserve connector polarity, route the cable away from mechanical strain and verify bias voltage plus vibration response before enabling alarms.

      FAQS

      • What type of sensor is 330500-02-CN?
        It is a 330500 Velomitor piezo-velocity sensor with integrated electronics for absolute vibration measurement.
      • Which mounting adapter is identified by 330500-02-CN?
        The 02 mounting code corresponds to an M8 x 1 mounting adapter.
      • What signal does 330500-02-CN provide?
        It supplies a velocity-proportional electrical output with nominal sensitivity of 3.94 mV/mm/s.
      • Which vibration surfaces suit 330500-02-CN?
        The datasheet identifies bearing housings, casings and structural vibration as the intended absolute-vibration measurement points.
      • Which connector is used by 330500-02-CN?
        The sensor uses a two-pin MIL-C-5015 connector.
      • How should 330500-02-CN be torqued?
        Apply 32 to 46 kg-cm, equivalent to 24 to 40 in-lb, through the mounting adapter.
      • How is polarity checked on 330500-02-CN?
        Motion toward the connector produces Pin A positive relative to Pin B.
      • What should be verified after replacing 330500-02-CN?
        Verify mounting integrity, cable polarity, output bias, channel scaling, vibration response and alarm operation.
