      330180-X1-05 MOD 145004-10

      Proximitor Sensor
      In Stock
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      3300 XL Proximitor Sensor
      35mm DIN rail mount with
      integrated electrical isolation
      High immunity, compliant
      with European CE mark approvals

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330180-X1-05 MOD 145004-10
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330180-X1-05 MOD 145004-10

      • Manufacturer:
        Bently Nevada
      • Product Category:
        General Automation
      • Spare Part Number:
        330180-X1-05 MOD 145004-10
      • Estimated shipping dimensions:
        8.8x3.5x7cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Total Length and Mounting Option:
        1.0 meter /9.0 meters/5.0 meters
      • Agency Approval Option:
        CSA, ATEX, IECEx Approvals
      • Scale Factor:
        Standard 200 mV/mil
      • Linear Range:
        10 to 90 mils
      • Power Supply:
        -24 Vdc
      • Output Voltage:
        Negative bias DC voltage proportional to gap
      • Target Material:
        Hitachi custom steel
      Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      The 330180-X1-05 MOD 145004-10 is a specialized 3300 XL series 5mm/8mm eddy current Proximitor Sensor manufactured by Bently Nevada. This product is a core component for the protection and condition monitoring of large, critical rotating machinery assets, accurately measuring radial vibration, axial displacement, and rotational speed of rotating shafts in a non-contact manner.
        • One 3300 XL 8 mm probe
        • One 3300 XL extension cable
        • One 3300 XL Proximitor Sensor
      While built upon the high-performance 3300 XL platform, this specific unit features the MOD 145004-10 custom modification, meaning it is factory-calibrated for non-standard shaft target materials (such as Hitachi KT5916S0 alloy steel) rather than standard AISI 4140 steel. Consequently, it does not share blind interchangeability with standard 3300 XL components. To maintain its calibrated scale factor and high accuracy, this Proximitor must be strictly paired with its designated customized sensor system and target material.

      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
       Bently Nevada 330180-X1-05 MOD 145004-10 Proximitor Sensor Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      Power Generation
      Monitors the radial vibration and axial displacement of large steam turbine generator shafts to prevent catastrophic rubbing between rotating and stationary parts.

      Oil & Gas
      Installed on high-pressure water injection pumps and high-power gas injection compressors on offshore platforms to monitor bearing oil film clearance in real time.

      Petrochemical
      Used on critical centrifugal compressors in hydrocracking and catalytic cracking units, ensuring uninterrupted production through continuous speed and shaft vibration monitoring.

      Iron & Steel Metallurgy
      Monitors the shaft conditions of blast furnace blowers and large converter gas recovery fans to prevent hazardous gas leaks or unplanned trips due to excessive vibration.

      Pulp & Paper Industry
      Used on headbox gear reducers and high-speed exhaust fans of large paper machines to eliminate unplanned downtime by monitoring bearing wear and vibration.

      Cement Manufacturing
      Monitors shaft vibration of large cement kiln induced draft fans and raw mill trains to prevent sudden failures caused by accelerated bearing wear in dusty environments.

       When using the 330180-X1-05 MOD 145004-10 Proximitor, the core priorities are strict asset matching, proper installation, and environmental protection. First, because it features the MOD 145004-10 special material calibration (e.g., Hitachi KT5916S0 steel), it must never be used on standard steel (like AISI 4140) or mixed with non-customized sensors, as this will cause severe measurement errors.

      Second, during installation, ensure perfect matching with the overall system length (typically 5m or 9m), alongside a stable -24Vdc power supply and solid electrical isolation at the DIN rail base.

      Lastly, route field wiring away from strong EMI sources, and protect coaxial connectors with insulating heat-shrink tubing against moisture and water ingress.

      Alternative Names

      330180-X1-05 MOD 145004-10 33O180-X1-O5 MOD 145OO4-1O 330180 X1 05 MOD 145004 10 330I80-XI-05 MOD I45004-I0 330180-X1-05 M0D 145004-10 33OI8O-XI-O5 MOD I45OO4-IO 33OI8O-XI-O5 M0D I45OO4-IO 330180-X1-00 MOD 145004-10 330180-X1-CN MOD 145004-10 330180-X1-BR MOD 145004-10 330180-11-05 MOD 145004-10

      Technical notes

      The 330180-X1-05 MOD 145004-102 is a core component of the Bently Nevada 3300 XL proximity transducer system. The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements. As the signal processing hub of this transducer system, the 330180-X1-05 MOD 145004-102 is a specially customized, non-standard Proximitor Sensor. It features a 35 mm DIN rail mount configuration with an electrically isolated base, and its internal circuitry is precisely tuned for a 5.0-metre total system length. Crucially, this unit incorporates the MOD 145004-102 special target material calibration, meaning it has been factory-calibrated for a specific non-standard alloy or special metal steel shaft surface instead of standard AISI 4140 steel, ensuring highly accurate and linear scale factors against non-standard target materials.

      FAQ View All FAQ

      • What is 330180-x1-05 mod 145004-10?
        It is a 3300 XL series 5mm/8mm Proximitor Sensor (eddy current sensor) manufactured by Bently Nevada.
      • What is the core function of 330180-x1-05 mod 145004-10?
        It measures shaft axial displacement, radial vibration, and speed of rotating machinery non-contactally using eddy current principles.
      • How does 330180-x1-05 mod 145004-10 work?
        It provides high-frequency RF signals to the probe and converts the impedance changes caused by the distance gap between probe tip and target into linear voltage outputs.
      • What probe system does 330180-x1-05 mod 145004-10 require?
        It must be paired with compatible 3300 XL 5mm or 8mm proximity probes and extension cables to form a complete 5-meter or 9-meter system.
      • Can 330180-x1-05 mod 145004-10 be repaired or directly replaced if damaged?
        This device is usually replaced as a whole industrial consumable or spare part. When replacing, the new unit's model and MOD suffix must match perfectly.
