The 330130-075-00-00 is a standard unarmored extension cable manufactured by Bently Nevada for the 3300 XL 8mm proximity transducer system. With a length of 7.5 meters (24.6 feet), this cable serves as the critical link connecting the field probe to the remote Proximitor sensor. It transmits high-frequency eddy current signals with minimal signal loss and high noise immunity, and is widely used for condition monitoring of heavy industrial rotating machinery.
One 3300 XL 8 mm probe
One 3300 XL extension cable
One 3300 XL Proximitor Sensor
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The 3300 XL 8 mm proximity transducer systems provide premium performance and support complete interchangeability of probes, extension cables (such as this 330130-075-00-00 7.5m cable), and Proximitor sensors, eliminating the need to match or bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable with other non-XL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330130-075-00-00 Extension Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas Exploration and Production
Used for radial vibration monitoring of gas compressors and water injection pumps on offshore drilling platforms and onshore oilfields to ensure 24/7 continuous operation.
Petroleum Refining
Monitors the axial displacement of large main air blowers and rich gas compressors in catalytic cracking units to prevent impeller collisions caused by bearing wear.
Thermal Power Generation
Employed for dynamic vibration and Keyphasor (speed) measurements on large steam turbine generator sets, boiler feedwater pumps, and forced/induced draft fans.
Nuclear Power Generation
Implements strict axial position monitoring for reactor coolant pumps and steam turbines in the conventional island of nuclear power plants, meeting extreme safety redundancy requirements.
Hydroelectric Power Generation
Used to monitor the radial swing (vibration) and thrust bearing displacement of hydro-turbine generator shafts, capturing shaft movements caused by hydraulic impacts.
Petrochemicals & Coal Chemical Industry
Applied to condition monitoring of high-power cracking gas compressors in ethylene plants and high-pressure oxygen compressors in coal-to-liquids (CTL) projects.
When using the 330130-075-00-00 extension cable, the following critical precautions must be strictly observed: Avoid excessive bending by maintaining a minimum bend radius of 25.4 mm (1.0 inch) during routing, and never kink the cable to prevent internal conductor breakage.
Protect coaxial connectors by ensuring they are only finger-tightened without tools, and always install connector protectors when deployed in oily or humid environments. Ensure impedance matching by using this cable exclusively within standard 3300 XL 8mm systems; never cut, splice, or alter its length, as this will destroy the 50Ω characteristic impedance and cause measurement errors.
The Bently Nevada 330130-075-00-00 is a 7.5-meter (24.6 ft) standard unarmored extension cable for the 3300 XL 8mm proximity transducer system. Featuring corrosion-resistant, gold-plated ClickLoc coaxial connectors and a high-performance fluoropolymer jacket, it reliably operates within a wide temperature range of -35°C to +177°C. It serves as a critical bridge connecting field probes to remote Proximitors, delivering low-loss, high-precision signal transmission for monitoring radial vibration, axial position, and speed in critical rotating machinery such as turbines and compressors.
It is an extension cable for the Bently Nevada 3300 XL 8mm proximity transducer system, used to transmit displacement signals.
How to use products like 330130-075-00-00?
Connect one end to the front-end 8mm probe and the other end to the Proximitor sensor to form a complete measurement circuit.
In which industrial scenarios is 330130-075-00-00 primarily applied?
It is primarily applied in asset protection for critical rotating machinery like turbines and compressors in oil, gas, petrochemical, and power generation industries.
What type of connector does 330130-075-00-00 use?
It uses standard ClickLoc corrosion-resistant gold-plated coaxial connectors, which achieve finger-tight locking without tools.
Does 330130-075-00-00 feature stainless steel armor protection?
No. Its suffix code 00 signifies a standard PVC jacketed cable, while the 01 suffix represents the armored version.
