Technical specifications for 330130-045-00-CN
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330130-045-00-CN
-
Estimated shipping dimensions:18x18x2cm
-
Weight:0.15 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Cable family:3300 XL standard extension cable
-
Cable length:4.5 m
-
Construction:Standard unarmored cable
-
Connector protector:Not included
-
Approval selection:Country-specific CN
-
System rule:Probe lead plus extension cable equals Proximitor electrical length
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 330130-045-00-CN completes the probe-to-Proximitor path with a 4.5 m standard coaxial section.
- Provides a 4.5 m calibrated extension section.
- Uses standard unarmored cable construction.
- Retains the country-specific CN approval selection.
- Operates only with a matched 3300 XL probe and Proximitor sensor.
The cable contributes to the calibrated electrical length of the transducer system. Connector condition, routing and family compatibility must be verified as part of the complete signal chain.
Important Notice: Compare the complete 330130-045-00-CN marking with the installed cable before disconnection. Record the restored gap voltage and proportional response before service release.
Bently Nevada 330130-045-00-CN Manuals & Downloads
Bently Nevada 330130-045-00-CN Official Technical Reference Excerpt (PDF)Bently Nevada 330130-045-00-CN Installation & Commissioning Guide (PDF)
The first document covers the product function, system role and technical selection. The installation guide covers identification, connection checks, commissioning and the acceptance record.
Electrical-length completion
Provides the 4.5 m extension section required by the matched 3300 XL transducer chain.
Probe-to-conditioner connection
Carries the calibrated coaxial signal from the probe lead to the Proximitor sensor.
Position measurement loop
Maintains the defined signal path for static shaft-position measurements.
Maintenance replacement
Restores a damaged cable section while preserving the selected system length.
Before installing Bently Nevada 330130-045-00-CN, confirm the documented system, interfaces and controlled configuration.
1
Compare the complete 330130-045-00-CN marking with the installed cable before disconnection.
2
Confirm the required standard unarmored cable construction and connector arrangement.
3
Do not shorten, splice or field-repair the calibrated coaxial cable.
4
Clean and inspect both ClickLoc interfaces before mating the connectors.
5
Provide strain relief and protect the cable from abrasion, heat and moving hardware.
6
Use the cable only inside a matched 3300 XL probe and Proximitor system.
7
Verify continuity and positive connector engagement before energizing the channel.
8
Record the restored gap voltage and proportional response before service release.
Technical notes
Compare the complete 330130-045-00-CN marking with the installed cable before disconnection. Record the restored gap voltage and proportional response before service release.
FAQ View All FAQ
-
What calibrated extension length is built into 330130-045-00-CN?The 045 field specifies 4.5 m.
-
Which cable construction is selected by the 00 field of 330130-045-00-CN?It selects standard cable without stainless-steel armor or connector protector.
-
How should the CN suffix be handled on 330130-045-00-CN?Retain the country-specific approval selection exactly and verify the installed marking.
-
Which 3300 XL components must be matched with 330130-045-00-CN?The probe lead, extension cable and Proximitor sensor must share the required electrical length and family.
-
Why must not be shortened 330130-045-00-CN?Changing cable length changes the calibrated electrical characteristics.
-
Which connector check is required before closing the machine 330130-045-00-CN?Confirm clean contacts, positive ClickLoc engagement and adequate strain relief.
-
How should be protected without armor 330130-045-00-CN?Route it in a protected path away from heat, abrasion, crushing and moving parts.
-
What readings should be captured after installing 330130-045-00-CN?Record bias voltage and proportional target response at the monitor channel.
