Technical specifications for 330130-040-10-CN
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330130-040-10-CN
-
Estimated shipping dimensions:30.5x30.5x4cm
-
Weight:0.56 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Cable Family:3300 XL standard extension cable
-
Part Family:330130
-
Cable Length:4.0 m
-
Cable Option:FluidLoc cable
-
Connector Protector:Not selected by code 10
-
Armor:Not selected by code 10
-
Agency Suffix:CN retained; meaning not decoded by the selected source
-
System Compatibility:3300 XL 8 mm and documented 3300 5 mm chains
-
Electrical Length Rule:Probe plus extension cable equals Proximitor system length
-
Nominal System Sensitivity:7.87 V/mm (200 mV/mil) with matched system
-
Reference Target:AISI 4140 steel
-
Connection Check:Clean, dry and mechanically secure coaxial joints
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 330130-040-10-CN adds a documented extension cable execution to the installed machinery-monitoring path.
- Provides a documented 4.0 m extension length.
- Uses FluidLoc cable for the selected cable execution.
- Belongs to the 3300 XL standard extension-cable family.
- Requires the probe and cable lengths to equal the matched Proximitor system length.
Extension cable length is an electrical-system selection, not only a routing dimension. The installed probe lead, extension cable and Proximitor must be checked together before the channel is accepted.
Important Notice: Preserve the CN suffix exactly and do not assign an approval meaning that is absent from the selected ordering table.
Bently Nevada 330130-040-10-CN Manuals & Downloads
Official 3300 XL Extension Cable Ordering Excerpt (PDF)Bently Nevada 330130-040-10-CN Installation & Commissioning Guide (PDF)
The Technical Reference organizes the exact ordering identity, applicable characteristics and system boundary for this extension cable. The Installation & Commissioning Guide covers identification, pre-installation checks, connections, functional verification and the acceptance record.
Probe-system completion
Complete the required electrical length between a compatible probe and Proximitor.
Wet-environment routing
Use the FluidLoc execution where the approved installation calls for that cable type.
Machine retrofits
Restore an exact four-metre cable without changing the calibrated chain.
Service replacement
Replace a damaged cable while preserving connector type and system length.
Use the complete Bently Nevada 330130-040-10-CN identity and the applicable controlled procedure before work.
1
Verify the complete 330130-040-10-CN marking before replacing any nearby cable.
2
Confirm that 4.0 m plus the probe lead equals the Proximitor system length.
3
Do not treat the CN suffix as a decoded approval without separate evidence.
4
Keep coaxial connector surfaces clean, dry and free of metal debris.
5
Route FluidLoc cable without crushing, pulling or tight bends.
6
Support the cable so machine vibration does not load the connector.
7
Do not splice or shorten the calibrated extension cable in the field.
8
Verify gap voltage, channel OK state and dynamic response after reconnection.
Technical notes
Preserve the CN suffix exactly and do not assign an approval meaning that is absent from the selected ordering table.
FAQ View All FAQ
-
What cable family is Bently Nevada 330130-040-10-CN?It is a 3300 XL standard extension cable.
-
What length is Bently Nevada 330130-040-10-CN?The 040 code selects a 4.0 m cable.
-
Which cable option is used by Bently Nevada 330130-040-10-CN?Code 10 identifies FluidLoc cable.
-
Does Bently Nevada 330130-040-10-CN include armor?Code 10 does not select an armored execution.
-
Does Bently Nevada 330130-040-10-CN include a connector protector?Code 10 selects FluidLoc cable without the protector option.
-
What does CN mean on Bently Nevada 330130-040-10-CN?The suffix remains part of the exact identity; its meaning is not decoded in the selected ordering table.
-
How is the correct system length checked for Bently Nevada 330130-040-10-CN?Add the probe lead and 4.0 m cable, then match the result to the Proximitor system length.
-
What must be tested after installing Bently Nevada 330130-040-10-CN?Check connector condition, gap voltage, channel OK state and dynamic signal response.
