Get a quick price for 330106-05-30-15-02-00
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 330106-05-30-15-02-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330106-05-30-15-02-00
-
Estimated shipping dimensions:1.2x1x69cm
-
Weight:0.05 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Transducer family:3300 XL 8 mm
-
Measurement principle:Non-contact eddy current
-
Mounting thread:M10 x 1 reverse-mount
-
Case construction:without armor
-
Unthreaded section:5 mm fixed
-
Overall case length:30 mm fixed
-
Integral lead length:1.5 m
-
Termination:Miniature ClickLoc coaxial connector
-
Approval selection:Not required
-
System rule:Probe plus extension cable equals the selected Proximitor electrical length
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 330106-05-30-15-02-00 places a 3300 XL 8 mm sensing tip at the machine measurement point through a M10 x 1 reverse-mount without armor case.
- Uses the M10 x 1 reverse-mount case defined for the 330106 probe family.
- Provides 5 mm fixed of unthreaded case and 30 mm fixed overall case length.
- Carries a 1.5 m integral lead with miniature clickloc coaxial connector.
- Operates as one component of the matched 3300 XL 8 mm transducer chain.
The probe converts target clearance into the calibrated electrical response of the complete proximity system. The installed probe, extension cable, Proximitor sensor and monitor configuration must remain matched.
Important Notice: Match the complete 330106-05-30-15-02-00 marking and the assigned machine point before removal. Record bias voltage, signal direction and dynamic response during final acceptance.
Bently Nevada 330106-05-30-15-02-00 Manuals & Downloads
Bently Nevada 330106-05-30-15-02-00 Official Technical Reference Excerpt (PDF)Bently Nevada 330106-05-30-15-02-00 Installation & Commissioning Guide (PDF)
The first document covers the product function, system role and technical selection. The installation guide covers identification, connection checks, commissioning and the acceptance record.
Shaft-relative vibration
Feeds non-contact shaft motion from the 3300 XL 8 mm sensing point into a matched monitoring channel.
Axial or radial position
Tracks static shaft position where the installed target and channel configuration permit.
Machine protection input
Supplies the conditioned transducer chain used for alarms, trips and condition monitoring.
Commissioning response check
Supports gap, polarity and proportional-response checks after installation.
Before installing Bently Nevada 330106-05-30-15-02-00, confirm the documented system, interfaces and controlled configuration.
1
Match the complete 330106-05-30-15-02-00 marking and the assigned machine point before removal.
2
Confirm the M10 x 1 reverse-mount mounting interface and usable thread engagement before tightening.
3
Keep the probe inside a matched 3300 XL 8 mm probe, extension-cable and Proximitor chain.
4
Protect the sensing tip, lead and ClickLoc contacts from impact, contamination and moisture.
5
Route the integral lead away from hot surfaces, rotating parts and sharp bend points.
6
Use only the connector hardware included by the selected cable option.
7
Set the initial gap against the approved target material before enabling alarms.
8
Record bias voltage, signal direction and dynamic response during final acceptance.
Technical notes
Match the complete 330106-05-30-15-02-00 marking and the assigned machine point before removal. Record bias voltage, signal direction and dynamic response during final acceptance.
FAQ View All FAQ
-
How does the 30 mm fixed body function inside the 3300 XL 8 mm chain for 330106-05-30-15-02-00?It belongs to the 3300 XL 8 mm proximity-transducer system.
-
Which mounting boss must match the M10 x 1 reverse-mount, 30 mm fixed interface of 330106-05-30-15-02-00?The probe case uses M10 x 1 reverse-mount.
-
How does its 5 mm fixed unthreaded section affect adjustment of 330106-05-30-15-02-00?The selected unthreaded section is 5 mm fixed.
-
What clearance confirms the 30 mm fixed body can reach the target for 330106-05-30-15-02-00?The ordering string specifies 30 mm fixed overall case length.
-
Why is the 1.5 m lead included in the 3300 XL 8 mm electrical length of the 30 mm fixed probe 330106-05-30-15-02-00?The probe contributes 1.5 m of integral cable to the matched electrical length.
-
What must be inspected on the Miniature ClickLoc coaxial connector fitted to the 30 mm fixed body of 330106-05-30-15-02-00?It uses Miniature ClickLoc coaxial connector.
-
Why must the extension cable stay paired with the 30 mm fixed/1.5 m probe 330106-05-30-15-02-00?Changing probe or extension-cable length changes the calibrated electrical path to the Proximitor sensor.
-
How do bias voltage and direction confirm the M10 x 1 reverse-mount, 30 mm fixed probe is gapped on 330106-05-30-15-02-00?A controlled target movement should produce the expected bias change and proportional channel response without diagnostic faults.
