      330104-05-13-10-02-00

      Armored Proximity Probe
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      A 1.0 m 3300 XL 8 mm M10 x 1 proximity probe with 50 mm unthreaded length, 130 mm case length, miniature coaxial clickloc without protector and the 00, not required selection.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330104-05-13-10-02-00
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330104-05-13-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330104-05-13-10-02-00
      • Estimated shipping dimensions:
        20.5x22.4x3.3cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        330104
      • Probe case thread:
        M10 x 1
      • Unthreaded length:
        50 mm
      • Case length:
        130 mm
      • Total probe length:
        1.0 m
      • Cable construction:
        75 ohm triaxial FEP with stainless-steel armor
      • Connector selection:
        Miniature coaxial ClickLoc without protector
      • Approval selection:
        00, not required
      • Linear range:
        2.0 mm (80 mils)
      • Recommended gap:
        About 1.27 mm at -9 Vdc
      • Scale factor:
        7.87 V/mm (200 mV/mil)
      • Frequency response:
        0 to 10 kHz
      • Probe tip:
        8.0 mm PPS
      • Minimum bend radius:
        25.4 mm
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330104-05-13-10-02-00 is a 3300 XL 8 mm M10 x 1 armored probe with 130 mm case length and 1.0 m total probe length.
      • M10 x 1 case thread
      • 50 mm unthreaded length
      • 130 mm case length
      • Miniature coaxial ClickLoc without protector

      This armored probe is the sensing end of a matched 3300 XL 8 mm transducer chain. Pair its probe-plus-extension length with the selected Proximitor Sensor, preserve the documented connector arrangement and verify the target material before calibration.

      Important Notice: Verify the complete 330104-05-13-10-02-00 marking, matched electrical length, connector selection and 00, not required record before installation; do not borrow another suffix.

      Bently Nevada 330104-05-13-10-02-00 Manuals & Downloads
      Bently Nevada 330104-05-13-10-02-00 Manufacturer Datasheet Excerpt (PDF)Bently Nevada 330104-05-13-10-02-00 Installation & Commissioning Guide (PDF)

      The manufacturer excerpt preserves selected original datasheet pages and is not the complete publication. The installation guide is an Apter Power field workflow for controlled restoration and commissioning.

      Radial vibration
      Measures shaft motion in a correctly engineered 3300 XL 8 mm channel.
      Axial position
      Supports static position measurement within the documented linear range.
      Phase reference
      Can form the probe end of a compatible phase-reference channel.
      Exact suffix renewal
      Restores the 330104-05-13-10-02-00 execution without borrowing another probe geometry.
      Bently Nevada 330104-05-13-10-02-00 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Read the full 330104-05-13-10-02-00 marking before removing the installed probe.
      2
      Record probe gap, target material, runout and monitor configuration before service.
      3
      Confirm M10 x 1, 50 mm unthreaded length and 130 mm case length.
      4
      Keep the cable route within the 25.4 mm minimum bend radius and protect the clickloc connector.
      5
      Join clean mating connectors finger tight; 0.565 N m is a maximum limit, not a tightening target.
      6
      Match probe-plus-extension length to the Proximitor Sensor electrical-length selection.
      7
      Restore the documented gap voltage and verify static and dynamic response before release.
      8
      Confirm the ordered 00, not required marking instead of assigning approval from the family name.

      Technical notes

      For 330104-05-13-10-02-00, retain the exact ordered suffix, installed measurement-chain record and witnessed acceptance result. Return the channel to service only after the model-specific electrical and mechanical checks pass.

      FAQ View All FAQ

      • What combination of reach and cable protection defines Bently Nevada 330104-05-13-10-02-00?
        This model combines a 50 mm unthreaded reach, 130 mm M10 x 1 case and stainless-steel-armored triaxial cable.
      • Where does the 50 mm unthreaded portion of Bently Nevada 330104-05-13-10-02-00 matter during installation?
        The probe holder and target clearance must accommodate that 50 mm unthreaded section without clamping or loading it.
      • What body length must an installed bracket accept for Bently Nevada 330104-05-13-10-02-00?
        The ordered case length is 130 mm, so the bracket position must be checked against that exact body dimension.
      • How should Bently Nevada 330104-05-13-10-02-00 be paired to achieve the selected channel length?
        Its 1.0 m probe lead must be combined with the appropriate extension so the sum matches the Proximitor Sensor electrical-length selection.
      • Which field connection should be prepared for Bently Nevada 330104-05-13-10-02-00?
        Prepare a miniature coaxial ClickLoc mating connection without relying on a connector protector, because this model uses connector option 02.
      • What static setup point is normally used for Bently Nevada 330104-05-13-10-02-00?
        The probe is normally positioned near the middle of the linear region, approximately 1.27 mm from the target at about -9 Vdc.
      • Which scale-factor result supports acceptance of Bently Nevada 330104-05-13-10-02-00?
        A correctly matched 3300 XL 8 mm channel should show the nominal 7.87 V/mm, or 200 mV/mil, scale factor.
      • Does Bently Nevada 330104-05-13-10-02-00 carry an approval requirement in its exact suffix?
        No. The ending 00 is the not-required approval option, and that specific selection should remain in the installation record.
