      200155-00-CN

      200155 low-frequency Trendmaster
      In Stock
      Ships by Thursday, September 17
      Fast Shipping Available

      Product Describe：

      This is a 200155 low-frequency Trendmaster Pro accelerometer supplied without a mounting stud.

      Its piezoelectric sensing element converts case vibration along the sensitive axis into a differential voltage proportional to acceleration for low-frequency machine monitoring.

      The accelerometer connects through its top-mounted 5-pin connector and is used with the applicable acceleration-to-velocity channel type in the Trendmaster Pro monitoring architecture.

      It is intended for low-frequency acceleration applications such as fin-fan and slow rotating shafts.

      Ask our team:

      Get a quick price for： 200155-00-CN
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 200155-00-CN

      Technical specifications for 200155-00-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        200155-00-CN
      • Estimated shipping dimensions:
        14.8x15.2x6.8cm
      • Weight:
        0.95 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Accelerometer family:
        200155 low-frequency Trendmaster Pro
      • Mounting stud:
        None supplied
      • Order-code suffix:
        CN
      • Sensitivity:
        100 mV/g (10.2 mV/m/s2), +/-12%
      • Acceleration range:
        +/-20 g peak
      • Frequency response:
        2 to 10,000 Hz
      • Excitation voltage:
        4.7 to 5.5 V DC
      • Current consumption:
        Less than 800 microA
      • Output bias:
        2.5 V DC +/-0.23 V
      • Case isolation:
        600 V rms
      • Shock survivability:
        5,000 g peak
      • Operating temperature:
        -40 to +105 C
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 200155-00-CN is a low-frequency trendmaster pro accelerometer configured for measurement range +/-196 m/s2 (+/-20 g) and frequency range 1.5 to 10000 Hz.
      • Measurement range: +/-196 m/s2 (+/-20 g)
      • Frequency range: 1.5 to 10000 Hz
      • Sensitivity: 10.2 mV/(m/s2)
      • Mounting stud: None

      Mounted on the machine case or bearing housing, the piezoelectric element converts structural acceleration along its sensitive axis into the electrical input used for vibration trending and assessment.

      Configuration control: Match the complete 200155-00-CN code, measurement range +/-196 m/s2 (+/-20 g), frequency range 1.5 to 10000 Hz and mating hardware before mounting or wiring.

      Apter Power 200155-00-CN Manuals and Guides

      The first link is the Apter Power product reference. The second link opens the manufacturer-published Bently Nevada datasheet for the applicable product family. Confirm the complete part number and installed configuration before use.

      1.5 to 10000 Hz vibration band
      200155-00-CN supplies a casing-acceleration signal across the documented frequency range.
      None mounting interface
      The selected mounting option couples the sensing base to the machine measurement surface.
      Bearing-housing response
      Captures structural vibration on pumps, motors, fans, compressors or other rotating equipment.
      Condition-monitoring input
      Feeds the compatible Trendmaster, 1900-series or applicable acceleration-monitoring channel.
      Before installing 200155-00-CN, confirm the complete catalog code, physical nameplate and selected monitoring-channel configuration.
      1
      Measurement range: +/-196 m/s2 (+/-20 g) is the exact selection for 200155-00-CN
      2
      Frequency range: Match 1.5 to 10000 Hz to the mating mechanical or electrical interface
      3
      Sensitivity: Retain 10.2 mV/(m/s2) when selecting the associated system components
      4
      Mounting stud: Verify None before final routing, mounting or commissioning
      5
      Housing material: Record 316L stainless steel in the channel and installation data for this model

      Technical notes

      Technical notes

      Select the machine-side mounting hardware separately because the -00 option does not provide a mounting stud.

      FAQS

      • What engineering function does 200155-00-CN perform in its monitoring loop?
        200155-00-CN converts machine-case acceleration along its sensitive axis into an electrical signal. The monitoring channel uses this signal to trend casing vibration and machine structural response.
      • Which measurement range applies to 200155-00-CN?
        The configured measurement range for 200155-00-CN is +/-196 m/s2 (+/-20 g).
      • What frequency range must be checked when specifying 200155-00-CN?
        Use 1.5 to 10000 Hz for the frequency range when reviewing this complete model.
      • How does the sensitivity selection affect 200155-00-CN?
        This configuration identifies sensitivity as 10.2 mV/(m/s2); include that value in the installation record.
      • Which mounting stud is associated with 200155-00-CN?
        The technical value is None for the mounting stud of this model.
      • What companion hardware should be confirmed for 200155-00-CN?
        Confirm specified mounting stud or adhesive interface, compatible accelerometer signal cable, acceleration or acceleration-to-velocity monitor input.
      • What is the first commissioning check for 200155-00-CN?
        Select the machine-side mounting hardware separately because the -00 option does not provide a mounting stud.
      • Where is 200155-00-CN applied and what signal behavior should the engineer verify?
        It is intended for low-frequency acceleration applications such as fin-fan and slow rotating shafts. Verify a stable response at the configured monitoring input before releasing the channel.
