What are the Connection Interfaces of the HESG447024R1 70BT01C?

The HESG447024R1 70BT01C has 2 × 9-pin D-sub Connection Interfaces.

What is the maximum number of stations for HESG447024R1 70BT01C?

The maximum number of stations for HESG447024R1 70BT01C is 32 devices per segment.

What is the output impedance of the HESG447024R1 70BT01C?

The output impedance of the HESG447024R1 70BT01C is 110 Ω.

Product image is representative; revision or series may vary. Contact us to request a specific version.

HESG447024R1 HEB67077-31B 70BT01C

Name: HESG447024R1 HEB67077-31B 70BT01C
Brand: ABB
SKU: 70BT01C

Bus Transmitter

In Stock

Product Describe：

Bus Transmitter
Common Mode Rejection
> 80 dB at 50 Hz
Output Impedance
110 Ω

Ask our team:

Phone:
+86 180 3023 5313
E-Mail:
sales13@apterpower.com

Get a quick price for： HESG447024R1 HEB67077-31B 70BT01C

Quantity*

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy.

Technical specifications FAQ

Technical specifications for HESG447024R1 HEB67077-31B 70BT01C

Manufacturer:

ABB
Product Category:

DCS System
Spare Part Number:

70BT01C
Estimated shipping dimensions:

1.7×20.5×14.7cm
Weight:

0.28 kg
Tariff Code:

8537101190
Counliy of origin:

SWEDEN
Connection Interfaces:

2 × 9-pin D-sub
Cable Length:

Up to 1000 m (at 9.6 kbps)
Maximum Stations:

32 devices per segment
Output Impedance:

110 Ω
Transmission Delay:

< 2 μs

Ask for Quote

FAQS

What are the Connection Interfaces of the HESG447024R1 70BT01C?

The HESG447024R1 70BT01C has 2 × 9-pin D-sub Connection Interfaces.
What is the maximum number of stations for HESG447024R1 70BT01C?

The maximum number of stations for HESG447024R1 70BT01C is 32 devices per segment.
What is the output impedance of the HESG447024R1 70BT01C?

The output impedance of the HESG447024R1 70BT01C is 110 Ω.
