Technical specifications for RDCU-02C ASXR7220
-
Manufacturer:ABB
-
Product Category:DCS Systems
-
Spare Part Number:ASXR7220
-
Estimated shipping dimensions:12.7x3.1x28.2cm
-
Weight:0.55 kg
-
Tariff Code:8537101190
-
Counliy of origin:Sweden
-
Power Supply:24 VDC
-
Communication Speed:1, 2, or 4 Mbit/s
-
Current Consumption:200 mA max.
-
Degree of Protection:IP20
-
Electromagnetic Emissions:EN 50081-2;CISPR 11
-
Optical Component Type:Agilent Technologies Versatile Link
Information
Overview
Manuals
Common Applications
Control Functions
The RDCU-02C ASXR7220 is a drive control unit module within the ACS800 series frequency inverter platform. The hardware contains a printed circuit board with a conformal coating treatment, denoted by the suffix C, to prevent damage from environmental moisture and chemical contamination.
- 250 mA base current consumption
- IP00 bare board protection rating
- ASXR7220 application firmware designation
The RDCU-02C ASXR7220 ABB Interconnect Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
ABB RDCU-02C ASXR7220 RDCU Drive Control Unit Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in t330101-00-16-10-01-05n.
Metallurgical Steel Rolling
Operates within hot or cold rolling main drive inverters to receive speed reference signals and calculate motor torque outputs.
Paper Industry
Deployed in paper machine multi-motor sectional drive systems to execute synchronous speed control across roller sections using tension sensors.
Mine Hoists
Controls heavy-duty AC motors of mine hoists, managing heavy-load startup and braking logic coordinated with mechanical brakes.
Oil and Gas Drilling
Controls AC/DC variable frequency operations of rig mud pumps, drawworks, and top drive systems, utilizing the coated circuit board to withstand field salt spray environments.
Power and Boiler Fans
Controls the variable frequency speed regulation of boiler induced and forced draft fans in power plants, transmitting operating parameters to the DCS via fieldbus cards.
Rubber and Plastics Compounding
Controls main motors of large internal mixers and extruders, monitoring current and torque feedback to prevent overload mechanical damage.
The RDCU-02C ASXR7220 manages drive control, signal processing, communication, and parameter handling within the ACS800 drive system. It interfaces with power modules, control panels, I/O circuits, and optional communication boards to support drive operation, monitoring, and maintenance.
Technical notes
The ASXR7220 designation identifies the specific system application firmware package version compatible with the underlying hardware processor. Through the onboard optical fiber ports, the module establishes direct communication with power units, upper automation controllers, or peripheral fieldbus adapter modules.
