Technical specifications for SD853 3BSE088188R1
-
Manufacturer:ABB
-
Product Category:DCS Systems
-
Spare Part Number:SD853 3BSE088188R1
-
Estimated shipping dimensions:8.1x13.1x12.9cm
-
Weight:1.16 kg
-
Tariff Code:8537101190
-
Counliy of origin:SWEDEN
-
Rated output current:10 A
-
Rated output power:240 W
-
Rated output voltage:24 V d.c.
-
Mains/input voltage, nominal:100-240 V a.c. 110-150 V d.c.
-
Mains frequency:50-60 HZ (+ - 6%)
-
Power Factor (at rated output power):0.99/0.97
-
Primary peak inrush current at power on:< 11 A
-
Heat dissipation:16.4 W / 12.1 W, 120/230 V a.c.
-
Ripple (peak to peak):< 50 mV
-
Output voltage regulation at max. current:max 50 mV 0 - 12 A
-
Maximum ambient temperature:70 °C
-
Protection rating:IP20 according to IEC 60529
-
Pollution degree:Degree 2, IEC 62477-1
-
Output over voltage protection:Max 32 V DC
-
Max ambient temperature:-25 °C (-13 °F) to +70 °C (158 °F), derating 6W / °C between 60 °C - 70 °C
-
Mechanical operating conditions:IEC 61131-2
Information
Overview
Manuals
Common Applications
Product Precautions
The SD853 3BSE088188R1 is a high-performance DIN rail DC power supply module from ABB. It belongs to ABB's System 800xA automation system platform and is the core power supply component for the S800 I/O module and its matching controller.
- High Redundancy Reliability
- Industrial-Grade Electrical Stability
- Seamless Integration with 800xA
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
ABB SD853 3BSE088188R1 SD853 Power Supply 10A Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas
Providing redundant power for Emergency Shutdown systems to ensure safe closure during critical events.
Power Generation
Powering auxiliary systems like lube oil pumps to prevent unit trips caused by a single power failure.
Petrochemical
Providing stable DC power to hundreds of field transmitters and control valves within refinery DCS.
Pulp & Paper
Powering paper machine drives to prevent paper breaks or defects caused by voltage fluctuations.
Mining & Metallurgy
Providing regulated power for S800 I/O stations monitoring mining machinery in high-vibration areas.
Cement Industry
Providing clean power for communication interface modules in high-EMI kiln control environments.
When using the SD853 (3BSE088188R1) power supply module, the primary considerations are the correct configuration of redundancy and the maintenance of the cooling environment. First, to achieve redundant power supply, the module must be used in conjunction with an SS823 or SS832 voting unit; direct paralleling of the outputs is strictly prohibited. It is also recommended to ensure independent input power sources for both modules to maximize reliability. Second, as the module generates heat during operation, sufficient ventilation clearance (typically at least 50mm above and below) must be maintained on the DIN rail, and dust should be cleaned regularly to prevent triggering thermal protection. Additionally, you should periodically monitor the output voltage to ensure it remains stable at 24V and check for any loose terminal wiring to avoid the risk of localized overheating or system power loss caused by poor contact.
FAQ View All FAQ
-
What exactly is the SD853 3BSE088188R1 device?It is a Power Supply Module from the S800 I/O system manufactured by ABB.
-
How to use products like the SD853 3BSE088188R1?It is mounted on a standard DIN rail, usually located in the power distribution layer of a control cabinet. Input power is connected via terminal blocks, and the output terminals provide power to AC 800M controllers, S800 I/O modules, or field instruments.
-
Does the SD853 3BSE088188R1 support redundant configuration?Yes. This is one of its primary design advantages. Two SD853 modules can be connected via a voting unit (such as SS823 or SS832) to achieve 1+1 redundancy. If one module fails, the other takes over the power supply seamlessly.
-
What do the LED indicators on the SD853 3BSE088188R1 represent?The LEDs on the front panel display the power status. A Green light (OK) indicates the output voltage is normal; if the light is off or changes color, it indicates an input power loss, internal fault, or output short circuit.
-
What are the primary industries for the SD853 3BSE088188R1?It is widely used in process industries requiring high-reliability control, such as petrochemicals, power monitoring, pulp and paper, pharmaceuticals, and water treatment within automation systems.
