FXDOM01

FAQS

• How many isolated output points are fitted to FXDOM01?
  For FXDOM01, the official Mitsubishi evidence records digital outputs as 8. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• Which networked FLEX I/O platform hosts FXDOM01?
  For FXDOM01, the official Mitsubishi evidence records network platform as ControlNet FLEX I/O. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• How does FXDOM01 implement channel-to-channel isolation?
  For FXDOM01, the official Mitsubishi evidence records isolation as Individual opto-isolation. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• What switching element does FXDOM01 use for each normally open output?
  For FXDOM01, the official Mitsubishi evidence records output contact as MOSFET N.O. PhotoMOS relay. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• Which output rating applies to FXDOM01 when a 1794-TB3 base is used?
  For FXDOM01, the official Mitsubishi evidence records output voltage with 1794-tb3 as 120 V DC / 120 V AC, 0.5 A. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• Which higher-voltage rating applies to FXDOM01 with a 1794-TBN base?
  For FXDOM01, the official Mitsubishi evidence records output voltage with 1794-tbn as 220 V DC / 230 V AC, 0.5 A. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• What maximum off-state leakage should an FXDOM01 acceptance test expect?
  For FXDOM01, the official Mitsubishi evidence records output leakage current as 10 microampere maximum. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
• What maximum on-resistance is specified for the FXDOM01 PhotoMOS output?
  For FXDOM01, the official Mitsubishi evidence records output on resistance as 3.2 ohm maximum. Apply that value only within the documented Mitsubishi Power DIASYS control system configuration and confirm the affected eight-channel isolated digital output switching on a ControlNet FLEX I/O network during controlled commissioning.
