Technical specifications for 10014/H/I
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:10014/H/I
-
Estimated shipping dimensions:4x18.5x12.8cm
-
Weight:0.35 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Electrical interface:RS-422; RS-485
-
System interface:FSC Central Part
-
Program storage:FLASH
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell 10014/H/I is an FSC communication module for RS-422 and RS-485 networks. It provides the balanced serial interface between the Fail Safe Controller Central Part and external equipment.
- Interfaces the FSC Central Part to balanced serial networks
- Supports RS-422 and RS-485 physical layers
- Carries configured process communication telegrams
- Uses flash-based communication firmware
10014/H/I installs with FSC Central Part, Shielded RS-422 or RS-485 cable, Configured serial peer, Termination and bias network in an engineered Fail Safe Controller configuration.
The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this rs-422/rs-485 communication module.
Important Notice: Confirm the complete 10014/H/I marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.
Apter Power 10014/H/I Manuals and Guides
Apter Power 10014/H/I Product Technical Reference PDFApter Power 10014/H/I Installation and Verification PDF
The first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
Multidrop safety-system integrationInterfaces the FSC Central Part to balanced serial networks
Long-distance package communicationSupports RS-422 and RS-485 physical layers
Balanced serial gateway linksCarries configured process communication telegrams
FSC network migrationUses flash-based communication firmware
Read the applicable Honeywell installation instructions before work. Verify 10014/H/I and the installed Fail Safe Controller configuration.
1Verify the complete 10014/H/I marking and its assigned Fail Safe Controller position before work.
2Isolate the energy associated with FSC Central Part before disconnecting 10014/H/I.
3Protect the 10014/H/I connectors and electronic assembly using approved ESD controls.
4Record the as-found Shielded RS-422 or RS-485 cable connections and configured assignment before replacement.
5Confirm Configured serial peer matches the approved installation record for 10014/H/I.
6Restore 10014/H/I under controlled conditions and review its model-specific diagnostics.
7Complete a documented functional test for multidrop safety-system integration before release.
Technical notes
Preserve polarity, shield treatment and termination locations, match every serial setting and verify read-only traffic before enabling control writes.
FAQ View All FAQ
-
How is 10014/H/I identified before installation in a Fail Safe Controller cabinet?Match the full 10014/H/I marking and part number 10014/H/I to the assigned position and installed FSC Central Part.
-
Which companion hardware must be checked when replacing 10014/H/I?Verify FSC Central Part, Shielded RS-422 or RS-485 cable and Configured serial peer against the approved cabinet and project record before fitting the RS-422/RS-485 Communication Module.
-
What wiring information should be recorded before removing 10014/H/I?Record terminal identifiers, polarity or phase, shields, cable tags and the as-found channel or port assignment for 10014/H/I.
-
How should engineers validate 10014/H/I after configuration?Restore the documented Fail Safe Controller assignment, review diagnostics and run a controlled test of its role: interfaces the fsc central part to balanced serial networks.
-
Can 10014/H/I be moved to a different slot or duty without review?No. Confirm keying, companion hardware and the approved configuration before assigning 10014/H/I to another position or function.
-
Which technical value is especially important during 10014/H/I commissioning?Verify Program storage is FLASH and use the named manufacturer procedure for the controlled functional test.
-
What should be checked if 10014/H/I does not support long-distance package communication after installation?Check seating, Shielded RS-422 or RS-485 cable, Configured serial peer, field energy and the model-specific diagnostics before replacing additional hardware.
-
What evidence should be retained after 10014/H/I returns to service?Retain the full model identity, as-left connections, configuration, diagnostic result and the final controlled test record for multidrop safety-system integration.
