Technical specifications for K7214
-
Manufacturer:HIMA
-
Product Category:DCS Systems
-
Spare Part Number:K7214
-
Estimated shipping dimensions:2x19x12.8cm
-
Weight:0.14 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Assembly function:Fusing and current distribution
-
Rated distribution current:120 A
-
Circuit-breaker slots:18
-
Distribution voltage:24 Vdc
-
System family:HIQuad X
-
Equipment class:Power supply current and distribution
Information
Overview
Manuals
Common Applications
Product Precautions
HIMA K7214 is a 24 Vdc fusing and current-distribution assembly for HIQuad X installations. It distributes cabinet power through eighteen circuit-breaker positions within the approved current architecture.
- Distributes 24 Vdc power through eighteen protected branch positions
- Provides a centralized fusing point for HIQuad X cabinet circuits
- Supports documented 120 A current-distribution architecture
- Separates branch-circuit protection for service and fault isolation
K7214 installs with HIQuad X safety cabinet, 24 Vdc cabinet supply, eighteen approved circuit breakers, protected module and field branches in an engineered HIMA HIQuad X Safety System configuration.
The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this 24 vdc fusing and current distribution assembly.
Important Notice: Confirm the complete K7214 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.
Apter Power K7214 Manuals and Guides
Apter Power K7214 Product Technical Reference PDFApter Power K7214 Installation and Verification PDFThe first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
Safety-controller cabinet power distributionDistributes 24 Vdc power through eighteen protected branch positions
Protected 24 Vdc I/O branch supplyProvides a centralized fusing point for HIQuad X cabinet circuits
Cabinet circuit-breaker organizationSupports documented 120 A current-distribution architecture
Power-distribution maintenance and fault isolationSeparates branch-circuit protection for service and fault isolation
Read the applicable HIMA installation instructions before work. Verify K7214 and the installed HIMA HIQuad X Safety System configuration.
1Verify K7214 and its assigned cabinet position before installation.
2Open and secure all upstream 24 Vdc feeders before touching the distribution assembly.
3Record every branch label, breaker rating and downstream load before replacement.
4Confirm the installed arrangement remains within the documented 120 A distribution architecture.
5Use only approved circuit breakers in the eighteen designated positions.
6Check supply polarity, conductor termination and protective bonding before energization.
7Energize and test branches individually while monitoring voltage and abnormal current.
8Retain the final breaker schedule and cabinet functional-test record.
Technical notes
Confirm feeder polarity, prospective current and branch identification, install the approved circuit breakers, then test each 24 Vdc branch separately before energizing the complete HIQuad X cabinet.
FAQ View All FAQ
-
Which installed hardware must be matched before using K7214?Match K7214 to HIQuad X safety cabinet, 24 Vdc cabinet supply and the complete physical marking; do not transfer a configuration from an adjacent model.
-
How should engineers isolate K7214 before replacement?Place the associated process function in its approved maintenance state and isolate the power, signal or pneumatic energy connected to HIQuad X safety cabinet.
-
What connection information should be recorded before removing K7214?Record every terminal, cable, channel, group and companion-component assignment associated with K7214 before any conductor or connector is moved.
-
Which configuration must be restored after installing K7214?Restore only the approved HIMA HIQuad X Safety System configuration for the original position, including the model-specific channel, network, timing or pressure settings.
-
How should K7214 be commissioned for Safety-controller cabinet power distribution?Apply a controlled input, output or operating condition and verify the expected distributes 24 vdc power through eighteen protected branch positions response together with the product-specific diagnostics.
-
Which diagnostics should be checked after replacing K7214?Review the applicable power, communication, channel and fault indications for K7214, then confirm that no unexpected alarm or bypass remains active.
-
Can K7214 be replaced by a similar family model without engineering review?No. The complete model, electrical or pneumatic execution, companion hardware and approved system configuration must match the installed duty.
-
What evidence should be retained after K7214 returns to service?Retain the full K7214 identity, as-left connections, restored configuration, final diagnostics and the controlled functional-test result.
