Technical specifications for F3349
-
Manufacturer:HIMA
-
Product Category:DCS Systems
-
Spare Part Number:F3349
-
Estimated shipping dimensions:2x19x12.8cm
-
Weight:0.14 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Module type:Safety-related digital output
-
Output channels:8
-
Nominal output voltage:24 V DC or 48 V DC
-
Maximum output current:500 mA per documented channel
-
Monitoring:Line and open-circuit supervision
-
Protection:Electronic short-circuit protection
-
Safety classification:SIL 3 in documented application
-
Revision record:Revisions 00 and 01 listed
-
Acceptance:Command, load and channel diagnostics
Information
Overview
Manuals
Common Applications
Product Precautions
F3349 drives eight monitored DC output channels in a safety-related I/O arrangement, with each field circuit matched to the documented voltage, load and diagnostic behavior.
- Exact model: F3349.
- Module type: Safety-related digital output.
- Output channels: 8.
- Nominal output voltage: 24 V DC or 48 V DC.
Retain the documented position, connections and configuration record. Complete controlled diagnostics and a functional test before service release.
Important Notice: Confirm F3349, every companion marking and the recorded acceptance result before replacement.
HIMA F3349 Manuals & Downloads
HIMA F3349 Technical Reference (PDF)HIMA F3349 Installation & Commissioning Guide (PDF)
The technical reference documents the exact product identity and engineering boundaries; the commissioning guide provides separate readiness, connection, verification and handover checks.
Installed-system renewal
Restores the documented F3349 position while keeping the approved host and interfaces.
Controlled maintenance
Supports as-found recording, safe isolation and exact connection restoration.
Compatibility review
Compares the full F3349 marking, host, connectors, settings and companion hardware.
Commissioning evidence
Records diagnostics and a controlled functional test of monitored switching of eight safety-related 24/48 V DC output circuits.
Read the applicable HIMA and site instructions before work. Verify F3349, the installed host and every connected circuit before isolation or replacement.
1
Confirm the complete F3349 marking before work.
2
Place the affected equipment in its approved maintenance state.
3
Isolate connected energy and prove the circuit safe.
4
Photograph the slot, wiring, connectors and settings before removal.
5
Match the documented HIMA safety-related I/O host and every companion component.
6
Restore mechanical retention, shielding and protective earth.
7
Review hardware and system diagnostics after energization.
8
Functionally verify monitored switching of eight safety-related 24/48 V DC output circuits before service release.
Technical notes
Match F3349 to the complete installed record. Preserve the host position, connections, settings and companion hardware; after replacement, verify diagnostics and monitored switching of eight safety-related 24/48 V DC output circuits under controlled conditions.
