Technical specifications for F3322
-
Manufacturer:HIMA
-
Product Category:PLC Systems
-
Spare Part Number:F3322
-
Estimated shipping dimensions:2.1x19.1x12.9cm
-
Weight:0.14 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product type:Digital output module
-
Output channels:16
-
Output voltage:24 VDC
-
Output current:Up to 0.5 A per documented channel
-
System family:H41q/H51q
-
Protective separation:ProtecS stated in the approval schedule
-
Replacement control:Preserve load groups and sixteen-output map
Information
Overview
Manuals
Common Applications
Product Precautions
HIMA F3322 occupies the documented HIMA H41q/H51q hardware position and connects the approved cabinet circuits to the installed control architecture.
- Exact HIMA F3322 identity
- HIMA H41q/H51q
- 16-Channel Digital Output Module
- Controlled replacement and acceptance
Retain the exact rack position, wiring, protective measures and engineering record. Commissioning must verify the affected function under controlled conditions.
Important Notice: Confirm the complete HIMA F3322 marking, lifecycle status, installed interfaces and recorded acceptance result before release.
