      IC697CPU731

      Controller CPU
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      GE IC697CPU731 is a single-slot 12 MHz Series 90-70 CPU with 32K battery-backed CMOS memory. It supports documented discrete and analog I/O through the Series 90-70 VME rack system.

      Ask our team:

      Get a quick price for： IC697CPU731
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for IC697CPU731

      Technical specifications for IC697CPU731

      • Manufacturer:
        General Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        IC697CPU731
      • Estimated shipping dimensions:
        4x21.8x29.1cm
      • Weight:
        0.5 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product family:
        Series 90-70
      • Processor clock:
        12 MHz
      • Processor:
        80C186
      • User memory:
        32K battery-backed CMOS, fixed
      • Discrete I/O:
        Up to 512 inputs and outputs in any mix
      • Analog I/O:
        Up to 8K analog inputs and outputs
      • Boolean execution:
        0.4 microsecond per Boolean function
      • Rack position:
        Slot 1 of an IC697CHS rack
      • Programmer port:
        RS-422/485 compatible serial port
      • Operating control:
        Three-position mode switch with password access
      • Status indication:
        Three CPU status LEDs
      • Configuration:
        Software configured; no DIP switches or jumpers
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Apply GE IC697CPU731 only in the documented Series 90-70 system position after checking its interfaces, companion hardware and configured values.
      • Executes Series 90-70 control logic with a 12 MHz 80C186 processor
      • Provides 32K of battery-backed CMOS user memory
      • Supports up to 512 discrete points and 8K analog points
      • Uses software configuration with a protected three-position operating switch
      Use GE IC697CPU731 in the approved system position and retain the documented interfaces, configuration and commissioning controls.
      Important Notice: Confirm the full IC697CPU731 marking, installed revision, compatible hardware and approved commissioning record before release.
      GE IC697CPU731 Manuals and Downloads
      GE IC697CPU731 Technical Reference (PDF)GE IC697CPU731 Installation & Commissioning Guide (PDF)
      The first document presents model-specific technical data. The second provides installation checks, commissioning steps and acceptance records.
      Machine control
      Executes documented Series 90-70 sequencing and interlock logic.
      Process control
      Coordinates approved analog and discrete I/O in a VME rack.
      Legacy CPU service
      Preserves program, configuration and rack-slot identity during replacement.
      Controlled restart
      Restores logic and I/O configuration before a staged run-mode test.
      Read the applicable General Electric instructions before work. Verify IC697CPU731 and the installed system configuration.
      1
      Verify the complete IC697CPU731 marking and installed revision.
      2
      Place the controller and connected equipment in the approved maintenance state.
      3
      Record the rack position, connections and interface assignments.
      4
      Back up the documented configuration and operating values.
      5
      Isolate power before removing the module or rack hardware.
      6
      Use ESD controls and seat all connectors evenly.
      7
      Restore only documented companion hardware and approved settings.
      8
      Verify diagnostics and controlled system response before release.

      Technical notes

      Technical notes

      Use only the complete GE IC697CPU731 identity and the current manufacturer publication. Verify the installed revision, companion hardware, wiring and saved configuration before replacement or release.

      FAQS

      • What processor does GE IC697CPU731 use?
        It uses a 12 MHz 80C186 processor.
      • How much user memory does GE IC697CPU731 provide?
        It provides 32K of fixed battery-backed CMOS user memory.
      • How much discrete I/O can GE IC697CPU731 support?
        The data sheet permits up to 512 inputs and outputs in any mix.
      • Where is GE IC697CPU731 installed?
        It is a single-slot CPU installed in slot 1 of an IC697CHS rack.
      • How is GE IC697CPU731 configured?
        It is software configured and has no DIP switches or configuration jumpers.
      • What must be recorded before replacing GE IC697CPU731?
        Record the complete GE IC697CPU731 marking, installed revision, system position, connections and approved configuration before removal.
      • What confirms successful commissioning of GE IC697CPU731?
        The exact GE IC697CPU731 identity, restored configuration, normal diagnostics and a controlled model-specific functional test must all agree with the approved record.
