Technical specifications for HE693PBS106
-
Manufacturer:General Electric
-
Product Category:PLC Systems
-
Spare Part Number:HE693PBS106
-
Estimated shipping dimensions:3.5 cm x 13 cm x 13.5 cm
-
Weight:0.3 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Supported Baud Rates:9.6 kbps to 12 Mbps
-
Max Nodes Without Repeater:Up to 32 devices
-
Max Nodes With Repeater:Up to 64 devices
-
Connector Type:9-pin D-sub
-
Profibus DP Port Slot Usage:Series 90-30 I/O rack slot
-
Operating Temperature:32 to 104 degrees
-
Power Supply:5 VDC backplane rail
Information
Overview
Manuals
Need More Info
- HE693PBS106 Profibus DP Slave Module
- Supports PROFIBUS-DP Communication for Industrial Networks
- Enables Slave Device Connectivity with Host Controllers
The GE HE693PBS106 from Horner Electric is a dedicated Profibus DP slave module, designed specifically for integration within a Profibus DP network. It accommodates baud rates ranging from 9.6 kbps up to a maximum of 12 Mbps, facilitating versatile communication options for various applications.
The HE693PBS106 module from Horner Electric serves as a Profibus DP Slave Module, specifically tailored for effective operation in Profibus DP networks. This unit supports a broad range of baud rates, spanning from 9.6 kbps to 12 Mbps, with the capability to reach a maximum baud rate of 12 MBd.
Connectivity is handled through a robust 9-pin D-sub connector, ensuring reliable physical interfacing. It is designed for installation in a Series 90-30 I/O system, making it easy to integrate into existing setups. Typical isolation of approximately 1500 VAC between field and logic provides additional safety and reliability during operation.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
GE HE693PBS106 Profibus DP Slave Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
We know that questions arise, and that sometimes you need more details or a closer look to make the right decision. That’s why we make it easy for you to reach out directly—so you’re never left wondering.
With our team, you’re just a message away from clarity and confidence. Whether you have a specific question, need a particular image, or want more details, the request form puts you in control. Let us know what you need, and we’ll bring the answers straight to you—no guesswork required!
FAQ View All FAQ
-
What type of HE693PBS106 module is this?It is a PROFIBUS DP slave module designed for GE Fanuc Series 90-30 PLCs.
-
What protocols does the HE693PBS106 support?The HE693PBS106 operates strictly as a PROFIBUS DP slave.
-
Is the HE693PBS106 compatible with Series 90-30?Yes, it is designed for use within the GE Fanuc Series 90-30 PLC system.
-
What software is used to configure it?It supports configuration using Logicmaster software.
-
Where can I find the manual?The technical documentation, specifically manual MAN0221, is available through Horner Automation's legacy documentation.
-
Is this HE693PBS106 module still in production?It is considered a legacy product, though available through specialized suppliers.
