Get a quick price for IC670MDL740
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for IC670MDL740
-
Manufacturer:General Electric
-
Product Category:PLC Systems
-
Spare Part Number:IC670MDL740
-
Estimated shipping dimensions:10.2x7.6x10.2cm
-
Weight:0.9 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Output points:16
-
Output grouping:One group
-
User input:10 to 30 V DC; 24 V DC nominal
-
Output voltage:9.2 to 29.5 V DC
-
Continuous current:0.5 A per point
-
Module current:4 A maximum
-
Minimum load:1 mA per point
-
Response time:200 us maximum on/off
-
BIU current draw:111 mA maximum
Information
Overview
Manuals
Common Applications
Product Precautions
IC670MDL740 provides sixteen positive-logic DC output points for a GE Field Control station.
- Provides sixteen grouped positive-logic outputs
- Switches externally supplied 12/24 VDC field loads
- Reports output and supply-related status locally
- Supports service replacement without disturbing documented terminal-base wiring
The module operates through a compatible Field Control bus interface and terminal base, switching externally powered 12/24 VDC loads as one group. Commissioning includes supply-polarity, common-fuse, channel-state and load-current verification.
Important Notice: Confirm IC670MDL740, terminal-base and bus-interface compatibility, station addressing, 16-point allocation, 10 to 30 VDC field supply, positive-logic polarity, common fuse, load current, grounding and controlled point-by-point test results before service.
Apter Power IC670MDL740 Manuals and Guides
- Apter Power IC670MDL740 Technical Data and System Reference PDF
- Apter Power IC670MDL740 Installation, Wiring and Acceptance Workbook PDF
The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.
Distributed solenoid control
Switches documented 12/24 VDC coils from a Field Control I/O station.
Machine actuator commands
Provides grouped DC commands to interposing devices in a distributed machine cell.
Panel indicator outputs
Drives approved low-current DC indication circuits within module limits.
Legacy Field Control maintenance
Restores a matching sixteen-point output position while preserving terminal-base wiring.
