KJ4006X1-BP1

Forty-Pin Mass Termination Block
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

Emerson KJ4006X1-BP1 provides a 40-pin mass-termination interface for the appropriate DeltaV S-series I/O arrangement. Its rotary keys must be set for the installed I/O card.
  • Manufacturer part number
    KJ4006X1-BP1
  • Shipping
    Swift global dispatch
  • Condition
    New, original product
  • Shipping size (est.)
    9.8cm x 4.2cm x 5.5cm
  • Country of Origin
    USA
Get a quick price for KJ4006X1-BP1
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 0

    Review your reference

    Send the complete KJ4006X1-BP1 reference, label photographs and required quantity. Check rotary keys, mass connector, card identity and the associated harness label.

  • 1

    Confirm the offer

    Review the offered KJ4006X1-BP1 execution, condition and included items. Confirm terminal block, harness and I/O card only if individually quoted in the quotation.

  • 2

    Arrange dispatch

    Swift global dispatch. Confirm quantity, dispatch date and delivery details for KJ4006X1-BP1 in the quotation.

  • Match the complete marking

    Match the complete Emerson KJ4006X1-BP1 marking and actual installed configuration. Check rotary keys, mass connector, card identity and the associated harness label.

  • Check the offered item before ordering

    Compare offered-unit photographs, interfaces and included items with the installed KJ4006X1-BP1 and its applicable installation requirements.

Technical specifications for KJ4006X1-BP1

  • Manufacturer:
    Emerson
  • Product Category:
    DCS Systems
  • Spare Part Number:
    KJ4006X1-BP1
  • Weight:
    0.08 kg
  • Tariff Code:
    8537101190
  • Termination interface:
    40-pin mass termination
  • Field-power rating:
    30 V DC at 3.2 A
  • Operating ambient:
    −40 to +70 °C
  • Relative humidity:
    5–95%, non-condensing
  • Shock rating:
    10 g, half-sine, 11 ms
  • Vibration, 2–13.2 Hz:
    1 mm peak-to-peak
  • Vibration, 13.2–150 Hz:
    0.7 g
  • Airborne contaminants:
    ISA-S71.04 G3

Information

Overview Downloads Applications / Compatibility Product Precautions
  • Emerson KJ4006X1-BP1 concentrates the field connection into a keyed termination interface, making card compatibility, harness pin assignment and controlled disconnection the main installation checks.
Compatibility control: Set rotary keys for the fitted I/O card
Harness verification: Preserve channel-to-pin assignment
Service acceptance: Verify the complete field circuit after reconnection
The terminal block must be paired with its intended I/O card and harness. The rotary keys support that pairing after installation, but they do not replace verification of the card identity or the field connection schedule.

The field-power rating belongs to the terminal-block assembly. Evaluate the installed card and channel limits separately, and keep the harness wiring consistent with the approved field circuit.

Removal with system power present is permitted only under the stated empty-card and disconnected-field-wiring conditions. The block has no user-serviceable parts and needs no calibration; acceptance depends on correct mating and end-to-end circuit checks.
Controller platform reference: DeltaV S-series I/O termination. Follow the applicable installation instructions and approved design.
Technical and service documents for Emerson KJ4006X1-BP1, covering the applicable hardware arrangement and engineering verification.
Original manufacturer pages retain their technical context. Use the Apter Power guide with the applicable manufacturer instructions and approved installation design.
System and supply context: Emerson KJ4006X1-BP1 serves the DeltaV S-series I/O termination arrangement. Evaluate the full connected signal or control path when selecting companion hardware.

Application scope: The applications below describe the installed measurement or control path. Select compatible companion equipment; accessories are included only when expressly itemized.
Prepare Emerson KJ4006X1-BP1 for its configured installation using these checks.
Identify card and harness pairing

Record the terminal-block identity, installed card, rotary-key positions and harness label. Preserve the pin-to-channel schedule and identify the affected field circuits.

Establish the disconnection condition

Place field circuits in their approved maintenance state. Apply the specified power-isolation procedure; if system power remains present, confirm that both the I/O card and all field wiring are absent as required.

Restore keys and connector engagement

Set the keys for the intended card and inspect all mating contacts. Refit the terminal block and approved harness without forcing the keyed interface or changing channel assignments.

Check each affected field path

Use the authorized test method for the connected I/O card to verify every affected channel. Compare field behavior with the card indication and application value.

Release the termination assembly

Restore the approved circuit and power sequence, then record key positions, harness identity and channel test results. Confirm cabinet conditions remain within the non-condensing operating envelope.

Configuration handover

Retain the final KJ4006X1-BP1 identity, tested settings and accepted channel or system response for subsequent maintenance.

Alternative Names

Emerson KJ4006X1-BP1

Technical notes

Keying and pinout: Set the rotary keys for the installed card and verify the harness channel mapping independently. Mechanical mating does not prove correct field assignment.

Conditional powered removal: System power may remain applied only when no I/O card is installed and no field wiring is connected to the terminal. Follow the complete hazardous-area service procedure.

Assembly versus channel limits: The terminal-block field-power rating is not an individual-channel rating. Apply the connected I/O card’s limits to each field circuit.

FAQ View All FAQ

  • Does the 40-pin connector on KJ4006X1-BP1 prove compatibility with any mass-wired I/O card?
    No. Match the card, rotary-key setting and harness pin assignment. Connector size alone does not establish electrical compatibility.
  • Under what conditions can KJ4006X1-BP1 be removed with system power still applied?
    Only when no I/O card is installed and no field wiring is connected to the terminal, subject to the complete applicable installation and hazardous-area procedure.
  • Why must the rotary keys on KJ4006X1-BP1 be set before the I/O card is fitted?
    They establish the intended card-to-terminal compatibility. Set them for the actual card rather than defeating the keying to force a connection.
  • Can the assembly power rating of KJ4006X1-BP1 be used as the allowable current of every channel?
    No. Individual-channel limits come from the connected I/O card and field circuit. Assess those separately from the terminal-block assembly rating.
  • How should a replacement harness connected to KJ4006X1-BP1 be verified?
    Compare its exact pin assignment with the approved circuit schedule and test each affected channel end to end before enabling the process.
  • What should be investigated when only some circuits fail after reconnecting KJ4006X1-BP1?
    Inspect the affected pins, harness mapping, card pairing and field wiring. A partially seated or misassigned connection can affect a subset of channels.
  • Is calibration a required maintenance activity for KJ4006X1-BP1?
    No calibration is required and the unit has no user-serviceable internal parts. Maintenance focuses on correct mating, keying, wiring and circuit verification.
  • Why should condensation be considered separately from humidity around KJ4006X1-BP1?
    The environmental rating is non-condensing. A cabinet can remain within a numerical humidity range while local condensation still makes the installation unsuitable.
